产品优势:
1、 采用国际先进的指纹算法,环境、气候的变化及手指受伤、脱皮的指纹识别能力显著提高,实现满指纹状态下识别时间小于1秒;
2、行业内率先采用智能感应节能指纹采集器,同时具备高级电源管理功能,达到低能耗产品设计效果;
3、指纹智能学习更新功能,实现一次注册终身使用,免去“后顾之忧”;
4、2,8英寸TFT彩屏显示,界面操作交互直观明了;
5、支持U盘下载考勤记录和指纹数据等功能。用户指纹可在一台机器注册后通过U盘进行共享,无需实时连接计算机;
产品参数:
型号 | A-E260 |
名称 | 免软件型考勤机 |
认证方式 | 指纹、密码 |
语言 | 中文或英文 |
显示屏 | 彩屏,2,8英寸TFT(320*240) |
指纹存储容量 | 800枚 |
记录容量 | 100,000 条 |
通讯方式 | |
感应卡 | 无 |
U盘上传/下载数据 | 支持 |
记录查询功能 | 有(员工通过认证后可查询自己的考勤记录) |
指纹采集器 | 感应节能型光学指纹采集器(分辨率:500DPI) |
CPU | 32bit CPU |
指纹智能学习更新 | 支持 |
识别角度 | 全角度识别 |
识别速度 | ≤1秒 |
拒真率(FRR) | ≤0,1% |
认假率(FAR) | ≤0,0001% |
工作方式 | 脱机 / 联机 |
指纹识别模式 | 1:1, 1:N |
语音提示 | 高清晰人性化语音 |
响铃功能 | 内置定时响铃 |
自检功能 | 支持 |
电源管理功能 | 睡眠,自动关机 |
电源适配器 | DC 5V/1A |
工作环境 | 温度:-10℃ ~ +60℃, 湿度(RH):20%~80% |
机器尺寸 | 178*134*30mm |
包装尺寸 | 248*166*70mm |
英文参数:
A-E260 Free Software Color Screen Fingerprint Time Attendance
(self-service)
Advantages:
1. Adopting the most advanced fingerprint algorithms, the identification ability to the fingerprint under the change of environment, climate and a finger injury, peeling fingerprint has significantly improved and can distinguish in one second under a full fingerprint state.
2.We are the first to use the intelligent sensor energy-saving fingerprint reader in the industry, along with the advanced power management features, can reduce the energy consumption effectively.
3.The fingerprints intelligent learning update function can implement registered for one time and use for a whole lifetime, that will relieve you from many troubles.
4.The using of a 2,8-inch TFT color display will makes your interface operation intuitive and clear.
5.Support U disk to download attendance records and fingerprint data and other functions.The user\'s fingerprint can register in one machine register and share by a U disk, and no need to connect to a computer in real time.
Technical Specification:
Model | A-E260 |
Type | Free Software Color Screen Fingerprint Time Attendance |
Authentication method | Fingerprint/Password |
Language | Chinese, English |
LCD Screen | 2.8 inch TFT Color Screen |
Fingerprint capacity | 800 |
Records capacity | 100,000 |
Communication | U disk |
Proximity card | Not support |
USB flash drive upload/download | Available |
fingerprint reader | Inductive energy-efficient optical fingerprint scanner(500DPI) |
CPU | 32bit CPU |
Fingerprints intelligent learning update | Support |
Recognition angle | Total angle |
Recognition speed | ≤1s |
FRR | ≤0,1% |
FAR | ≤0,0001% |
Operating mode | Off-line / Online |
Authentication mode | 1:1, 1:N |
Voice prompt | High-definition humane voice |
Bell | Built-in Timing Bell |
Self-test function | Support |
Power management Function | Sleep, automatic shutdown |
Power | DC 5V/1A |
Work environment | Temp:-10℃ ~ +60℃, humidity:20%~80% |
Terminal size | 178*134*30mm |
Package size | 248*166*70mm |
'
