Description
The BLM2008E uses advanced trench technology to provide
excellent RDS(ON), low gate charge and operation with gate
voltages as low as 2.5V. This device is suitable for use as a
load switch or in PWM applications .It is ESD protested.
General Features
● VDS = 20V,ID =6A
RDS(ON) < 30m @ VGS=2.5V
RDS(ON) < 24m @ VGS=4.5V
ESD Rating: 2000V HBM
● High Power and current handing capability
● Lead free product is acquired
● Surface Mount Package
Application
●PWM application
●Load switch
Schematic diagram
Marking and pin Assignment
TSSOP
