全自动机械手式灌装旋盖机DTGNX-III

机械手式双头液体灌装机是我公司近年来开发研制之最新产品，以微电脑设定步数蠕动泵执行计量灌装（特殊场合采用精密陶瓷泵）并具有自动灌装，自动加内塞，旋盖多种功能。该机配置了国内独一无二的专用机械手，下内塞及旋盖采用摆臂形式，下盖准确，旋盖采用伺服电机扭力模式，旋盖松紧度一致，调节方便从而实现完全自动化。

特点：

1.微电脑设定，装量精确，操作方便。

2.灌装系统可定制回吸功能，无滴漏。

3.采用机械手自动加内塞，旋外盖。

4.自动停机功能，对任一轨道出现连续无灌装，无外盖情况可自动停机。

技术参数：

适用规格：2-30ml

生产能力：40-60/分钟

灌装精度：≤±0.5%;

电源：22V50HZ

旋（轧）盖率：≥99%

自动上塞率：≥99%

气源：2m3/h  0.4-0.8Mpa

功率：1.0KW

机器净重：400KG

外形尺寸：2400*1100*1500mm

Manipulatortype double liquid filling machine is the latest product of my company developed in recent years, with the

microcomputer steps set wriggle pump machine adopts precision ceramic pump) (special occasions and has the automatic

filling, automatic plug, screw cover a variety of functions. Under the machine configuration domestic unique dedicated

manipulator, and screw cap in the form of swing arm, accurate under cover, screw cap adopt servo motor torque mode,

screw cap firmness, convenient adjustment so as to realize fully automated.

Features:

1. The setting of the microcomputer, the load precision, convenient operation.

2. The filling system can be customized to suction function, no drop leak.

3. Using manipulator automatic brush, spiral cover.

4. Automatic stop function, for any orbital consecutive without filling, automatic stop without cover.

Technical parameters:

Applicable specifications: 2-30 ml

Production capacity: 40-60 / minute

Filling accuracy: + / - 0.5% or less;

Power supply: 22 v50hz

Spin (rolling) cover rate: 99% or higher

Automatic plug rate: 99% or higher

Source: 2 m3 / h, 0.4 to 0.8 Mpa

Power:
1.0 KW

Machine net weight: 400 kg

Dimension: 2400 * 1100 * 1500 mm
