产品名称:标准型4色柔版印刷机

Product name:improvement type bridge type 4 color soft version printing machine

产品编号:WJY-40800II

Product serial number:FXD-70800II

产品简介:主要用于4色的的较复杂的图案的专色印刷或双面2色同时印刷或层次版印刷

Product brief introduction:main used for onlying have four color of of printing or two-sided dichromatic in the meantime printing or layer version printing

印刷色数

4色（任意增减）

Printing color

4Special color/

印刷宽度

1800mm

Matecial feeding width

1800mm

过料宽度

2000 mm

Lead to anticipate width

2000mm

印刷长度

190~1016mm(7.5″~40″)、(7.5″~60″)、(7.5″~80″)

printing length

190~1016mm(7.5″~40″)、(7.5″~60″)、(7.5″~80″)

起落版方式

日本油压或气压系统

printing plate lifting

Pneumatic /Hydraulic Press conntrol-JAPN

最高机械速度

150米/分

Mechanical speed

150m/min

最高印刷速度

120米/分

printing speed

120m/min

网纹辊

80~170DK       德国

Anilox cylinder

80DK-170DK(Germany)/180LPI-800LPI

套准精度

纵向±0.01mm(手动) / 横向±0.01mm(手动)

Register precision

ongitude:±0.01mm Transverse:±0.01mm

放卷直径

600 mm / 800 mm

Unwinder DIA

600 mm / 800 mm

收卷直径

600 mm / 800 mm

Rewinder DIA

600 mm / 800 mm

压印力

机械调节

Stamping strength

Machinery adjustment

干燥方式

电加热

Dry way

Electric heating

电热

32kw

Electrical heater

32kw

电热送风机

1.1KW

Blower of heater

1.1KW

主马达

5.5KW (减速比1:5) -台湾

Master motor

5.5KW- Taiwan

主变频

Panasonic变频器调速-日本

Master frequency converter

The Panasonic change the Pin machine adjust soon- Japan

行墨马达

370w - 台湾

Inkking motor

370W- Taiwan

普通轴承

日本NSK

Common bearings

NSK in Japan

单向轴承

德国ASNU

One-way bearings

ASNU in Germany

机械尺寸

4m×2.0m×2.7m

Dimension

4m×2.0m×2.7m

 承印材料

Accept to print material

PVC  35~70μm         OPP  20~70μm

BOPP 20~60μm         PE   35~100μm

NY   20~50μm         PET  20~60μm

CPP  20~60μm         纸张 20~150g/㎡

 主要配置说明

Main llocation elucidation

1  操作简单方便,套色准确,使用寿命长

1. The operation is simply convenient, the setting of the color is accurate, and of longer         working life.

2  采用台湾马达,日本变频调速,节省电,运行波动小

2.Adopt Taiwan motor, speed controller inverter made in Japan, electricity saving,and with stable circulate motion .

3  落板自动停止行墨马达，起板自动开始行墨装置

3. The falling-board will automatic stop the motor,the rising-board will automatic start the equipment.

4  供墨方式为胶网辘刮墨,单面刮刀三套

4. Provide ink by rubber roller's turning round.

5  采用特制模数直齿齿轮传动,印刷尺寸准确

5. Adoption specially made mold number to keep gears moving ,make certain that the printing size is accurate .

6  设有吹风发热两套装置,其中发热采用中央恒温控制系统并分组控制，冷风定型装置

6. Be equipped with blower and heater ,the heater facility use central constant-temperature control ,and the equipment of cold stereopia.

7  低辊采用德国特殊钢材加工，并经过特殊工艺处理,并电镀10丝厚的硬铬保护层

7. The roller adopted special steel of Germany ,through special technique processing, and with chrome protection layer by electroplating wire.

8  铝合金导轮进行硬质氧化、动平衡、静平衡处理

8. The aluminum alloy is used for the hard anode oxidation ,moving balance,motionless balance.
