Hardware |
|
Main Chipset |
Realtek RTL8188CUS |
|
Host interface |
USB2.0, type A connector |
|
LED |
Link/ Activity |
|
RF |
|
Antennas |
Built-in wire antenna (Peak Gain: -2dBi) |
|
Operation Frequency |
2412~2483.5 MHz |
|
Typical Transmit Power
(Onboard-Without
antenna) |
802.11b (CCK) 11Mbps: 18+/-1dBm |
Typical Transmit Power (Onboard-Withoutantenna)802.11g (OFDM) 54Mbps: 15.5+/-1dBm
Typical Transmit Power (Onboard-Withoutantenna)802.11n (HT20@MCS7), 14+/-1dBm
Typical Transmit Power (Onboard-Withoutantenna)802.11n (HT40@MCS7), 14+/-1dBm
|
Receive Sensitivity
(Onboard-Without
antenna) |
802.11b: -86+/-1dBm @ 11Mbps |
Receive Sensitivity (Onboard-Withoutantenna)802.11g: -74+/-1dBm
Receive Sensitivity (Onboard-Withoutantenna)802.11n (HT20), -70+/-1dBm
Receive Sensitivity (Onboard-Withoutantenna)802.11n (HT40), -67+/-1dBm
|
Software |
|
Operation System |
Windows XP,Vista,Win7 ;Mac OS X and Linux |
|
Security |
WEP , WPA, WPA2, WAPI, QoS (802.11e and WMM), |
|
Operation Conditions |
|
Voltage Range |
DC 5.0 V ± 5% |
|
Current Range |
140+/-5mA @ 802.11g, 54Mbps; 185+/-5mA @802.11b , 11Mbps |
|
Operating Temperature |
-10°C - 60°C |
|
Storage Temperature |
-20°C - 80°C |
|
Operating Humidity |
RH 95% (Non-Condensing) |
|
Storage Humidity |
RH 95% (Non-Condensing) |
|
Physical Specification |
|
Dimensions |
32.5x14.2x7.2mm |
|
Weight |
3.6g |
深圳市奥金瑞科技有限公司创建于2004年2月，是一家以射频技术(数字多媒体、无线网络）产品研发、生产、销售为一体的高新科技型企业。
奥金瑞人立足创新产品，潜心产品技术研发，注重产品品质和诚信服务，以“时尚、简单、可靠”的理念设计、生产和销售产品、服务，以供市场；公司在不断的产品研发实践中积累了丰富的产品开发经验，并具有深厚的自主知识产权设计、技术积累以及创新的技术研发，通过技术的不断创新，为客户提供最具竞争力的数字多媒体和无线网络产品。
“以客户能持续满意购买为宗旨 “是奥金瑞人始终如一的追求，“多、快、好、省”为客户提供优质、安全、可靠的技术和产品是奥金瑞永恒的方针，我们将不断的超越自我，一如既往地为客户创造价值，提供更加物美价廉的产品和一流的服务！
主营：wifi网卡、wifi模块、wifi插座、智能家居类产品，专注无线产品研发生产10年，品质铸造品牌！
联系人：文生150-1921-8160
QQ:1903650596 期待与您携手合作！
.
