PG系列电缆接头

材料：黄铜镀镍 平紧件：尼龙塑料(PA) 密封件：丁腈橡胶(NBR) 0-密封圈：丁腈橡胶(NBR) 防护等级：IP68-10巴压力(旋紧部位) 环境温度：-40℃至100℃,短时至120℃ Material：Brass nickel plated Claw：Nickel plastic(PA) Sealing：NBR 0-Sealing ring：NBR Protection level：IP68-10bar pressure(fixed installation and with 0-sealing ring) Ambient temperature：-40℃-100℃.temporary：to 120℃ 金属电缆防水接头 PG系列防水型 Metal Cable Mseries Waterproof type 产品特：特殊平紧爪与平紧圈之设计，夹紧电缆范围大，抗拉力强，可防水，防尘抗尘抗盐、耐弱酸、酒精、油、油脂及一般溶剂。 Character：Special design of clamping claw and clamping ring,wide clamping range,high stretching resistance,wate proof,dustproof,salt resistant,resistant for weak acid,alcohol,oil,grease and gengral solvent 螺牙规格AG Specification of thread 适用电缆 Cable Range 螺牙外径 Outer diameter of thread 机板口径 Mounting hole diameter 螺纹长度GL Thread length 螺纹长度加长型GL Thread lenght(langthened type) 接合长度H Joint length 板手径 Wrench diameter PG7 6.5-3 12.5mm 12.5-12.7mm 7mm 10mm 19mm 14mm PG9 8-4 15.2mm 15.2-15.4mm 8mm 10mm 20mm 17mm PG11 10-5 18.6mm 18.6-18.8mm 8mm 10mm 21mm 20mm PG13.5 12-6 20.4mm 20.4-20.6mm 8mm 15mm 22mm 22mm PG16 14-10 22.5mm 22.5-22.7mm 9mm 15mm 23mm 24mm PG19 14-10 25mm 25-25.2mm 9mm 15mm 25mm 24/27mm PG21 18-13 28.3mm 28.3-28.5mm 9mm 15mm 27mm 30mm PG25 22-15 32mm 32-32.2mm 10mm 15mm 29mm 35mm PG29 25-18 37mm 37-37.2mm 11mm 15mm 31mm 40mm PG36 33-25 47mm 47-47.2mm 12mm 15mm 37mm 50mm PG42 38-32 54mm 54-54.2mm 13mm 15mm 38mm 57mm PG48 44-37 59.3mm 59.3-59.5mm 14mm 15mm 38mm 65mm PG63 52-42 72mm 72-72.2mm 15mm 20mm 42mm 77mm

乐清市博伦电气有限公司是金属电缆防水接头M型、防电磁金属电缆防水接头、金属电缆防水接头PG型、金属电缆防水接头G型NPT型、黄铜塞帽、尼龙电缆固定头、TH焊接式金属电缆接头、TJ夹紧式金属电缆接头、多孔金属电缆接头、金属软管接头等产品专业生产加工的有限责任公司(自然人投资或控股),公司总部设在柳市智广工业区,乐清市博伦电气有限公司拥有完整、科学的质量管理体系。乐清市博伦电气有限公司的诚信、实力和产品质量获得业界的认可。欢迎各界朋友莅临乐清市博伦电气有限公司参观、指导和业务洽谈。
