NXZ-120 性能特点
1.液压等主要元件均采用国际品牌。Main components includes hydraulic parts are using famous international brand parts.
2.先进的机电一体化控制系统,油电两用,高效节能。Advanced elec-mechanic control system, diesel-electric hybrids, energy efficient.
3.豪华驾驶室设计符合人体工程学,视野开阔,操作舒适。Luxurious cab design accords with Human Engineering, brand vision and comfortable operation.
4.稳定性强,各种恶劣工况场地均能轻松应对,工作效率高,系统可靠,具有超强的装卸能力,在任何条件下都可以发挥完美的工作性能。Strong stability, can easily cope with all kinds of bad working conditions, high efficiency, reliable system, strong ability of loading and unloading, perfect performance in any conditions.
5.装载高度可随意调节,可随意装卸各种高度不同的车辆,履带行走适应各种恶劣路况。Adjustable loading height , handling various heights of different vehicles, crawler walking is adapt to all kinds of bad road conditions.
6.传送带传送速度快效率高。Speed of transmission belt is quick and efficient.
7.可以根据客户不同场地的需求随机定制。 Customized products according to the different needs of customers.
NXZ-120型技术参数
整车长度(运输)Overall Length (transportation) | 14000mm |
整车宽度(运输)Overall Width (transportation) | 3600mm |
整车长度(工作)Overall Length(working) | 16500mm |
整车宽度(工作)Overall Width(working) | 3600mm |
行驶速度Travel speed | 5 km/h |
最小转弯半径 Min. turning radius | 12500mm |
传送带传输速度 Speed of conveyor belt | 1.4m/s |
发动机功率 Engine Power | 55kw |
电机功率 Motor Power | 22kw |
卸载高度 Unloading Height | 5500mm |
卸载距离 Unloading Distance | 5200mm |
装载高度(最高/最低)Load Height (Max. /Min.) | 4500mm/2400mm |
