2920贴片SMD可恢复保险丝，030L/050L/075L/100L多种可选
'
产品价格是样品参考价，还有更多型号，
免费打样，包运费。具体价格请联系本人。
本厂是制造厂，量大从优，可开17%增值税发票。
可代替聚鼎、瑞侃、力特、富致等品牌。
具体规格参数如下：
JK-SMD030L PPTC DEVICES Edition：A0 Part Number：Q/JKTD-60-030 Page No: 1 OF 3 |
Table1 :DIMENTION(Unit : mm) Model | Marking | A | B | C | D | Min. | Max. | Min. | Max. | Min. | Max | Min. | JK-SMD030L | JK030L | 6.73 | 7.98 | 4.80 | 5.44 | 0.60 | 1.15 | 0.30 |
Table2 :PERFORMANCE RATINGS: Model | Vmax (Vdc) | Imax (A) | Ihold @25℃ (A) | Itrip @25℃ (A) | Pd Typ (W) | Maximum Time To Trip | Resistance | Current (A) | Time (Sec) | Rimin (Ω) | Rityp (Ω) | R1max (Ω) | JK-SMD030L | 60.0 | 100 | 0.30 | 0.60 | 1.500 | 1.50 | 3.00 | 0.600 | 0.900 | 4.800 |
Table3:Test Conditons and Standards Item | Test Conditon | Standard | Initial Resistance | 25℃ | 0.60～4.800�6�8 | IH | 25℃，0.30A， 60min | No Trip | Ttrip .trip | 25℃，1.50A | ≤3.0s | Trip endurance | 60V，100A， 1hr | No arcing or burning |
Operating Temperature：-40℃ TO 85℃ Packaging：Bulk ,2000pcs per bag
|
'
