产品价格是样品参考价，还有更多型号，
免费打样，包运费。具体价格请联系本人。
本厂是制造厂，量大从优，可开17%增值税发票。
可代替聚鼎、瑞侃、力特、富致等品牌。
具体规格参数请联系刘海平，如下是JK-MSMD1812-020规格：
JK-mSMD020 PPTC DEVICES Edition：A0 Part Number：Q/JKTD-30-020 Page No: 1 OF 3 |
Table1 :DIMENTION(Unit : mm) Model | Marking | A | B | C | D | E | Min. | Max. | Min. | Max. | Min. | Max | Min. | Min | JK-mSMD020 | JK020 | 4.37 | 4.73 | 3.07 | 3.41 | 0.50 | 1.00 | 0.30 | 0.25 |
Table2 :PERFORMANCE RATINGS: Model | Vmax (Vdc) | Imax (A) | Ihold @25℃ (A) | Itrip @25℃ (A) | Pd Typ (W) | Maximum Time To Trip | Resistance | Current (A) | Time (Sec) | Rimin (Ω) | Rityp (Ω) | R1max (Ω) | JK-mSMD020 | 30.0 | 100 | 0.20 | 0.40 | 0.8 | 8.0 | 0.02 | 0.350 | 0.800 | 5.000 |
Table3:Test Conditons and Standards Item | Test Conditon | Standard | Initial Resistance | 25℃ | 0.350～5.000�6�8 | IH | 25℃，0.20A， 60min | No Trip | Ttrip .trip | 25℃，8.0A | ≤0.02s | Trip endurance | 30V，100A， 1hr | No arcing or burning |
Operating Temperature：-40℃ TO 85℃ Packaging：Bulk ,1500 pcs per bag
|
'
