Construction;
A helically convoluted PTFE(polytetrafluorethylene) inner tube.
Standard wall,with an outer cover of AISI 304 high tensile stainless steel braid.
High pressure hose giving good flexibility and kink resistance.
Temperature:-70℃---260℃
Fitting:
Hose fittings with PTFE tail;
Hose fittings with hydraulic tail;
Industrial fittings.
SKCL630
内管：波纹状的PTFE（可订做防静电内衬）
外管：SS304不锈钢编织
温度：-70℃～260℃
特性：非常柔软，易清洗，易排水，质轻，符合FDA和USP认证
应用：广泛应用于各种工业领域。可输送食品，饮料，化学品，油品，热水，高温液体，高温气体。平滑螺旋面是专门用来防液体堵塞和凝固，使之更易清洗和消毒。
|
规格
(size) |
内径I.D(mm) |
钢丝外径(mm) |
最小壁厚(mm) |
弯曲半径
(mm) |
工作压力
(bar) |
爆破压力
（bar） |
重量
（kg/m） |
|
最小 |
最大 |
最小 |
最大 |
|
1/4" |
6.10 |
6.70 |
9.30 |
9.90 |
0.75 |
18 |
172 |
517 |
140 |
|
5/16" |
7.90 |
8.50 |
12.30 |
12.90 |
0.60 |
20 |
138 |
414 |
160 |
|
3/8" |
9.50 |
10.20 |
12.80 |
14.50 |
0.65 |
20 |
138 |
414 |
152 |
|
1/2" |
12.45 |
13.08 |
17.80 |
19.20 |
0.80 |
25 |
103 |
310 |
253 |
|
5/8" |
15.70 |
16.38 |
21.80 |
24.00 |
0.80 |
51 |
83 |
248 |
304 |
|
3/4" |
19.00 |
19.65 |
24.00 |
27.00 |
1.00 |
64 |
69 |
207 |
374 |
|
7/8" |
21.84 |
22.86 |
27.94 |
29.46 |
1.00 |
76 |
57 |
172 |
460 |
|
1″ |
25.50 |
26.16 |
32.20 |
36.10 |
1.00 |
89 |
46 |
138 |
543 |
|
1-1/4″ |
31.95 |
32.46 |
40.20 |
41.30 |
1.00 |
125 |
34 |
103 |
635 |
|
1-1/2″ |
38.00 |
38.90 |
47.80 |
49.00 |
1.00 |
152 |
30 |
90 |
840 |
|
2″ |
50.90 |
51.90 |
60.50 |
62.30 |
1.10 |
200 |
23 |
69 |
1000 |
|
3″ |
71.20 |
78.80 |
89.50 |
98.70 |
1.20 |
310 |
20 |
80 |
1500 |
|
4″ |
98.00 |
105.00 |
120.70 |
131.25 |
1.30 |
380 |
15 |
60 |
2000 |
|
|
|
|
|
|
|
|
|
|
|
'
