型 号Model

RHP

30

63

80

100

120

140

150

225

408

500

800

1000

1500

控制系统System

平衡调温调湿控制系统（BTHC），以P.I.D.方式控制|SSR Balance thermostat humidity control system (BTHC), the PID control of SSR

温度范围Temperaturerange

-70℃～150℃

湿度范围Humidity Range

20～98%R.H

温度波动度Temperature Constancy

±0.5℃

湿度波动度Humidity Constancy

±2.5%R.H

温度偏差Temperaturedeviation

±2.0℃

湿度偏差Humiditydeviation

±3%R.H(≥75%R.H时)/±5.0%R.H(＜75%R.H时)

升温时间Heat up time

-70℃～150℃约60分钟以内Within 60min

降温时间Pull down time

20℃～-70℃约75分钟以内Within 75min

内箱尺寸Internaldimension(cm)

W

30

40

40

40

40

50

50

50

60

70

100

100

100

H

40

45

50

50

50

56

60

75

85

85

100

100

100

D

25

35

40

50

60

50

50

60

80

80

80

100

150

外箱尺寸Externaldimension(cm)

W

87

97

100

100

100

100

105

105

115

120

160

160

160

H

150

155

143

150

150

150

150

165

175

175

190

190

200

D

88

100

85

110

110

110

110

120

140

140

140

160

180

内箱材质Internal material

SUS304高级不锈钢板SUS304 Senior stainless steel

外箱材质Externalmaterial

SUS304高级不锈钢板或钢板静电喷涂表面处理Stainless steel plate or steel SUS304 advanced electrostatic spray surface treatment

保温材质Insulation material

高密度聚胺酯泡沫及玻璃纤维High poly amino ester foam and glass fiber

冷冻系统Refrigeration system

气冷式/水冷式Air type/water-cooled

单段/复叠式，全密闭式压缩机，环保冷媒(R404a/R23)Single section/cascade type, all closed compressor, environmental protection, cold media

控制器Controllor

TEMI 8805.7英寸LCD彩色触摸屏，中/英文显示 TEMI880 color LCD screen，5.7 inches in English/Chinese

保护装置Safety Devices

无 熔丝开关、压缩机超压、过热、过电流保护、超温保护、风机超载保护、保险丝、干烧机保护器、缺水保护开关、故障警告系统、警报器No welding wire switch，compressor，overheating，over current protection，overtemperature protection，blower load overload protection，fuse，dry heating machine protector，water protection switch，fault warning system，alarm

标准配件Standard Accessories

28×34cm三层真空层观察窗1个、11W节能照明窗口灯1支、ф5cm测试孔1个（附不锈钢孔盖1只、硅胶塞头1只）、不锈钢SUS #304方型冲孔钢板置物架2套、内藏式不锈钢水箱（20L）、电源线2米、USB预留接口一个、电源线4.0 mm²x4蕊，低阻抗橡胶电缆线2.5m长1条、保险丝一套（易损件）、标准测试用不织布5片、控制器使用说明书一套、操作说明书一套、测试报告一份28×34cm three-layer viewing window a vacuum, 11W energy saving lamp lighting window 1, ф5cm test hole one (with a stainless steel manhole covers, silicone plugs a), SUS # 304 stainless steel square punching glove 2 sets of racks, Built-in stainless steel water tank (20L), power cable 2 meters, USB interface, a reserved, power cord 4.0 mmx4 core, low-impedance rubber cable 2.5m long one, fuse a set of (wearing parts), Standard test nonwoven 5, the controller uses a set of instructions, a set of operating instructions, a test report

选配件Options

另加测试孔、另加置物架、记录仪、计算机通讯接口、联机软件、大玻璃窗、逆渗透纯水机、产品合格证、电气原理图、制冷/除湿系统图、产品材料明细表、保修卡、外购件合格证Plus a test hole, plus racks, recorders, computer communication interface, online software, large windows, reverse osmosis water machine, product certification, electrical schematics, cooling / dehumidification system diagram, the product bill of materials, warranty card, certificate purchased parts

使用环境Ambient

5℃～35℃、≤85%RH、86～106Kpa

电源功率Power

AC380±10%50HZ三相四线+保护地线3 phase 4wires+Ground Wire

注：
1.以上数据均在环境温度（QT）25℃，工作室无负载条件下测得；
2.可根据用户的具体要求定做非标型“恒温恒湿试验室”、“高低温试验箱”、“低温试验箱”。
