链号

链号

节距

滚子直径

内节内宽

销轴直径

销轴长度

内链板高度

链板厚度

 极限拉伸载荷

平均拉伸载荷

每米长重

P

d1 max

b1 min

d2 max

L max

Lc max

h2 max

T max

Q min

Qo

q

mm

mm

mm

mm

mm

mm

mm

mm

kN

kN

kg/m

C208ASS

C208ALSS

C2040SS

C2042SS

25.40

7.95

15.88

7.85

3.96

16.6

17.8

12.0

1.50

8.46

10.02

0.50

0.84

C208AHSS

C2040HSS

25.40

7.95

7.85

3.96

18.8

19.9

12.0

2.03

8.46

10.32

0.65

C208BSS

C208BLSS

25.40

8.51

7.75

4.45

16.7

18.2

11.8

1.60

10.80

11.64

0.55

0.89

C210ASS

C210ALSS

C2050SS

C2052SS

31.75

10.16

19.05

9.40

5.08

20.7

22.2

15.0

2.03

13.32

16.86

0.78

1.27

C212ASS

C212ALSS

C2060SS

C2062SS

38.10

11.91

22.23

12.57

5.94

25.9

27.7

18.0

2.42

19.08

22.08

1.12

1.61

C212AHSS

C212AHLSS

C2060HSS

C2062HSS

38.10

11.91

22.23

12.57

5.94

29.2

31.6

18.0

3.25

19.08

24.96

1.44

2.07

C216ASS

C216ALSS

C2080SS

C2082SS

50.80

15.88

28.58

15.75

7.92

32.7

36.5

24.0

3.25

34.02

39.42

2.08

3.12

C216AHSS

C216AHLSS

C2080HSS

C2082HSS

50.80

15.88

28.58

15.75

7.92

36.2

39.4

24.4

4.00

34.02

42.00

2.54

3.58

C220ASS

C220ALSS

C2100SS

C2102SS

63.50

19.05

39.67

18.90

9.53

40.4

44.7

30.0

4.00

53.10

61.56

3.01

4.83

C220AHSS

C220AHLSS

C2100HSS

C2102HSS

63.50

19.05

39.67

18.90

9.53

43.6

46.9

30.0

4.80

53.10

67.44

3.56

5.38

C224ASS

C224ALSS

C2120SS

C2122SS

76.20

22.23

44.45

25.22

11.10

50.3

54.3

35.7

4.80

76.20

88.38

4.66

7.66

C224AHSS

C224AHLSS

C2120HSS

C2122HSS

76.20

22.23

44.45

25.22

11.10

53.5

57.5

35.7

5.60

76.20

96.54

5.26

8.26

C232ASS

C232ALSS

C2160SS

C2162SS

101.60

28.58

57.15

31.75

14.27

64.8

69.6

47.8

6.40

136.08

167.34

8.23

11.95

C232AHSS

C232AHLSS

C2160HSS

C2162HSS

101.60

28.58

57.15

31.75

14.27

68.2

73.0

47.8

7.20

136.08

171.48

9.06

12.77
