一、产品说明Product description
TSA型钢制“S”型称重传感器，承受拉、压外力均可，输出对称性好，结构紧凑、安装方便，规格齐全。可用于制造机电结合秤、吊钩秤、料斗秤及各种专用秤、工艺秤等
二、安装尺寸Mounting dimension
三、技术参数Technical data
额定载荷Emax（Max. capacity） | kg | 5~20000 |
灵敏度Sensitivity | mV/V | 2.0±0.002 |
精度等级uracy class | | C2 | C3 |
最大检定分度数Maximum number of verification intervals | nmax | 2000 | 3000 |
最小检定分度值Minimum load cell verification interval | Vmin | Emax/2000 | Emax/3000 |
综合误差Combined error | %F.S | ≤±0.020 | ≤±0.015 |
蠕变Creep | %F.S/30min | ≤±0.020 | ≤±0.015 |
温度对灵敏度影响Temperature effect on sensitivity | %F.S/10℃ | ≤±0.02 | ≤±0.017 |
温度对零点影响Temperature effect on zero | %F.S/10℃ | ≤±0.02 | ≤±0.017 |
零点平衡Zero balance | %F.S | ±1.0 |
输入电阻Input resistance | Ω | 380±10Ω |
输出电阻Output resistance | Ω | 350±3Ω |
工作温度范围Service temperature range | ℃ | -30...+70 |
安全过载Safe overload | %F.S | 120 |
极限过载Ultimate overload | %F.S | 200 |
推荐激励电压mended excitation voltage | V | 5…15 |
绝缘电阻Insulation resistance | MΩ/50V | ＞5000 |
密封等级Protection class | | IP67/IP68 |
传感器材料Load cell material | | 合金钢Alloy steel |
接线电缆Cable length | m | 3 |
电缆直径Cable outer caliber | mm | Φ5 |
