No.

序号

Items/项目

Rated Performance/额定性能

Remarks/备注

1

Nominal Capacity/标称容量

3600mAh

Discharge at 0.2C after standard charge fully.

按0.2C标准完全放电。

Minimum Capacity

最小容量

3540mAh

2

Nominal Voltage/标称电压

3.7V

3

End-of-Voltage at end of Discharge

放电截止电压

2.5V

±0.1

4

End-of-Charging Voltage/

充电截止电压

4.2V

5

AC Impedance /电池阻抗

≤200 mΩ

AC 1KHz

6

Standard charge current

标准充电电流

800mAh

7

Standard discharge current

标准放电电流

800mAh

8

Fast Charge/快速充电

0.5C CC/CV →0.05C cutoff

Charge time/充电时间: Approx 2.5h.

9

Fast Discharge/快速放电

0.5C CC→2.5V cutoff

10

Maximum Continuous Charge Current/最大持续充电电流

1500mA

11

Maximum Continuous Discharge Current/最大持续放电电流

1500mA

12

Operation Temperature Range

工作温度范围

Charge充电: 0~45℃

Humidity /湿度60±25%

Discharge放电: -20~50℃

13

Storage T/H Range

存储温、湿度范围

-20~50℃/60±25%

14

Weigh/重量

Approx/大约:90g

15

Product Dimension/ 产品尺寸

长度Length: 55 mm(MAX)

Initial dimension

初始尺寸
