Rexolite 是一种独特的交联聚苯乙烯微波塑料。
可提供的尺寸
| Rexolite® 1422 Sheet Size |
| Thickness (inch) | Thickness (mm) | Specification(mm) | LBS / SQ.FT | KG/㎡ |
| 0.01 | 0.254 | 610*610 |
|
|
| 0.015 | 0.381 |
|
|
| 0.02 | 0.508 |
|
|
| 0.031 | 0.787 | 305*305
305*610
610*610
610*1220
915*915 | 0.17 | 0.831 |
| 0.046 | 1.168 | 0.26 | 1.270 |
| 0.062 | 1.575 | 0.34 | 1.661 |
| 0.093 | 2.362 | 0.51 | 2.492 |
| 0.125 | 3.175 | 0.68 | 3.322 |
| 0.187 | 4.750 | 1.02 | 4.984 |
| 0.25 | 6.350 | 1.36 | 6.645 |
| 0.375 | 9.525 | 2.05 | 10.016 |
| 0.5 | 12.700 | 2.72 | 13.290 |
| 0.625 | 15.875 | 3.41 | 16.661 |
| 0.75 | 19.050 | 4.1 | 20.032 |
| 1 | 25.400 | 5.4 | 26.384 |
| 1.25 | 31.750 | 6.8 | 33.224 |
| 1.5 | 38.100 | 8.2 | 40.065 |
| 2 | 50.800 | 10.9 | 53.257 |
| 2.5 | 63.500 | 14 | 68.403 |
| 3 | 76.200 | 16 | 78.175 |
| 3.5 | 88.900 | 19 | 92.833 |
| 4 | 101.600 | 22 | 107.491 |
| 5 | 127.000 | 27 | 131.921 |
| 6 | 152.400 | 33 | 161.236 |
| Rexolite® 1422 Rod Size |
|
| Diameter (inch) | Diameter (inch) | Diameter(mm) | Length(mm) | LBS/FT | KG/m |
| 1/16″ (.062″) | 0.062 | 1.575 | 1220
1830
2440
3660 | 0.001 | 0.002 |
| 3/32″ (.093″) | 0.093 | 2.362 | 0.003 | 0.005 |
| 1/8″ (.125″) | 0.125 | 3.175 | 0.006 | 0.008 |
| 5/32″(」56″) | 0.156 | 3.962 | 0.009 | 0.013 |
| 3/16″ (.187″) | 0.187 | 4.750 | 0.013 | 0.019 |
| 1/4″ (.250″) | 0.25 | 6.350 | 0.022 | 0.033 |
| 9/32″ (.281″) | 0.281 | 7.137 | 0.028 | 0.042 |
| 5/16″ (312″) | 0.312 | 7.925 | 0.035 | 0.052 |
| 3/8″ (.375″) | 0.375 | 9.525 | 0.050 | 0.074 |
| 7/16″ (.437″) | 0.437 | 11.100 | 0.068 | 0.101 |
| 1/2″ (.500″) | 0.5 | 12.700 | 0.089 | 0.132 |
| 9/16″ (.562″) | 0.562 | 14.275 | 0.110 | 0.164 |
| 5/8″ (.625″) | 0.625 | 15.875 | 0.140 | 0.208 |
| 3/4″ (.750″) | 0.75 | 19.050 | 0.200 | 0.298 |
| 7/8″ (.875″) | 0.875 | 22.225 | 0.270 | 0.402 |
| 1″ (1.00″) | 1 | 25.400 | 0.350 | 0.521 |
| 1-1/8″ | 1.125 | 28.575 | 0.450 | 0.670 |
| 1-1/4″ | 1.25 | 31.750 | 0.550 | 0.819 |
| 1-3/8″ | 1.375 | 34.925 | 0.670 | 0.997 |
| 1-1/2″ | 1.500 | 38.100 | 0.790 | 1.176 |
| 1.5/8″ | 1.625 | 41.275 | 1220
2440 | 0.940 | 1.399 |
| 1-3/4″ | 1.75 | 44.450 | 1.080 | 1.608 |
| 1-7/8’1 | 1.875 | 47.625 | 1.250 | 1.861 |
| 2″ | 2 | 50.800 | 1.420 | 2.114 |
| 2-1/4″ | 2.25 | 57.150 | 1.800 | 2.679 |
| 2-1/2’1 | 2.5 | 63.500 | 2.210 | 3.290 |
| 2-3/4” | 2.75 | 69.850 | 305
610
915
1220 | 2.700 | 4.019 |
| 3″ | 3 | 76.200 | 3.200 | 4.763 |
| 3-1/4″ | 3.25 | 82.550 | 3.700 | 5.508 |
| 3-1/2″ | 3.5 | 88.900 | 4.400 | 6.550 |
| 3-3/4″ | 3.75 | 95.250 | 5.000 | 7.443 |
| 4″ | 4 | 101.600 | 5.700 | 8.485 |
| 4-1/4″ | 4.25 | 107.950 | 6.400 | 9.527 |
| 4-1/2″ | 4.5 | 114.300 | 7.200 | 10.717 |
| 4-3/4″ | 4.75 | 120.650 | 8.000 | 11.908 |
| 5″ | 5 | 127.000 | 8.900 | 13.248 |
| 5-1/2″ | 5.5 | 139.700 | 10.700 | 15.927 |
| 6″ | 6 | 152.400 | 12.700 | 18.904 |
| 7″ | 7 | 177.800 | 17.500 | 26.049 |
| 8″ | 8 | 203.200 | 305
610
915 | 22.900 | 34.087
|
