Max.swing over bed

320mm

Max.swing over gap

470mm

Max.turning dia.over cross slide

198mm

Max.length to be turned

880mm/ 1000mm

Speed steps

8

Speed range

70~2000rpm

Spindle bore dia

38mm

Taper of spindle bore

MT No.5

Longitudinal

0.079~1.291

Transverse

0.017~0.276

Metric threads

0.4~7

Whitworth threads

4~60

Cross slide travel

160mm

Top slide travel

76mm

Swiveling angle of turret

?45 ?

Distance from the tool bearing surface to centerline

18mm

Movement of tailstock quill

100mm

Taper of tailstock quill bore

MT No.3

Power of main drive motor

1.1or1.5KW

Packing size(1 package)

168x75x140cm / 185x75x140cm

Gross weight(kg)

560 / 600

Packing size(3 package)

＆#9312; 168x74x75cm /＆#9312; 185x74x75cm
＆#9313; 69x40x37cm＆#9314; 69x40x30cm

Gross weight(kg)

＆#9312;490/＆#9313; 30/＆#9314; 27/＆#9312;530/＆#9313;30/＆#9314; 27
