网带规格： 链条标号节距P链杆节距P1链杆直径D网丝直径D1网带螺距L网带节距J
（P）（p）（p1）（D）（D1）（L）（J）
C2042 25.4mm 25.4×*节5~8mm 1.0~1.6mm 3~19mm 6.35~25.4mm
C2052 31.75mm 31.75×*节6~10mm 1.2~2.0mm 5~21mm 6.35~31.75mm
C2062 38.1mm 38.1×*节8~12mm 1.5~2.0mm 8~21mm 6.35~38.1mm
C2082 50.8mm 50.8×*节10~12mm 1.5~3.0mm 10.5~21mm 12.7~50.8mm
C2160 101.6mm 101.6×*节10~14mm 1.5~4.0mm 10.5~27mm 12.7~50.8mm
丝径1.2、1.4、1.6、1.8、2.0、2.2、2.4、2.6----4.5不等
[编辑本段]
网带选择参考 怎样选择输送网带的各种材料
How to specify material of various conveyor belts
材料名称
Designation | C | Mn | Si | Ni | Cr | 其他元素
Other elements | 性能properties |
|
耐温
Temperature
-resistance | 耐酸
Acid resistance |
|
|
|
|
|
|
|
1~3号乙类钢
GB700-65 | 0.06~0.22 | 0.25~0.6 | 0.12~0.3 |
|
|
| 300° | 耐磨
Abrasion resistance |
1Cr13 | ≤0.12 | ≤0.60 | ≤0.60 |
| 12~14 |
| 600° |
|
1Cr18Ni9 | ≤0.08 | ≤2.00 | ≤0.80 | 8~11 | 17~19 |
| 600°~700° |
|
1Cr18Ni9Ti | ≤0.08 | ≤2.00 | ≤0.80 | 8~11 | 17~19 | Ti0.8 | 700°~750° | 做防酸防锈腐蚀
Acid rust and corrossion resistance |
OCr18Ni12Mo2Ti | ≤0.08 | ≤2.00 | ≤0.80 | 12~14 | 16~18 | Ti0.3~0.8
Mo1.8~2.5 | 750° |
|
OOCr18NIi14Mo2 | ≤0.03 | ≤2.00 | ≤1.00 | 12~16 | 16~19 | Mo1.8~2.5 | 700°~800° | 耐酸腐蚀
Strong-acid resistance |
1Cr25Ni20 | ≤0.20 | ≤2.00 | ≤1.00 | 17~20 | 22~25 |
| 1000° |
|
OCr25A15 | ≤0.06 | ≤0.7 | ≤0.6 |
| 23~27 | A1 4.5~6.5 |
|
|
Cr20Ni80 | ≤0.15 | ≤0.7 | 0.4~1.3 | 75~78 | 20~23 | A1≤0.5 | 1150° |
|
OOCr18Ni14Mo2Cu2 | ≤0.03 | ≤2.00 | ≤1.00 | 12~16 | 17~19 | Mo1.2~2.5
Cu1.0~2.5 |
| 耐重酸重腐蚀应用在维尼纶厂的醛化机上
Strong-acid resistant can be used cerbonylator on vinylon |
长城网带技术参数:
网带型号 | 金属条厚度㎜ | 金属条宽度㎜ | 螺距㎜ | 节距㎜ | 串条直径 | 网边型式 |
FW2.5/8.0 | 2.5 | 20 | 31 | 27.3 | 8.0 | 1、马蹄链型式
2、链条型式
3、镦头型式样 |
FW2.0/8.0 | 2.0 | 22 | 40 | 50.8 | 8.0 |
|
FW2.5/2.5 | 2.5 | 16 | 37.4 | 28.3 | 5.0 |
|
FW2.0/5.0 | 2.0 | 15 | 52.5 | 31.75 | 5.0 |
|
FW1.5/3.0 | 1.5 | 12 | 52.5 | 31.75 | 3.0 |
|
FW1.2/3.0 | 1.2 | 10 | 22.5 | 12.7 | 3.0 |
|
