供应8M同步带、进口同步带、深圳加红胶同步齿带
同步带工作原理：
同步带传动是由一条内周表面设有等间距齿的环形皮带和具有相应齿的带轮所组成，运行时，带齿与带轮的齿槽相啮合传递运动和动力，它是综合了皮带传动、链传动齿轮传动各自优点的新型带传动。
产品性能：
1）材料：聚氨酯，钢丝，凯夫拉
2）加布加胶：可在齿面/带背加绿布，背面加聚氨酯
3）机械性能：尺寸稳定，预拉力低，噪音低，高度耐磨损，弹性好，高精度的直线定位等
4）聚氨酯开口带成品标准卷长为50米或100米
| 圆弧齿同步带-HTD8M | | | | | | |
| 节距:8MM | | | | | | |
| 规格 | 节线长 | 齿数 | | 规格 | 节线长 | 齿数 |
| Specification | Section line length | Tooth number | | Specification | Section line length | Tooth number |
| 8M-320 | 320 | 40 | | 8M-808 | 808 | 101 |
| 8M-328 | 328 | 41 | | 8M-816 | 816 | 102 |
| 8M-344 | 344 | 43 | | 8M-824 | 824 | 103 |
| 8M-352 | 352 | 44 | | 8M-832 | 832 | 104 |
| 8M-360 | 360 | 45 | | 8M-840 | 840 | 105 |
| 8M-368 | 368 | 46 | | 8M-848 | 848 | 106 |
| 8M-376 | 376 | 47 | | 8M-856 | 856 | 107 |
| 8M-400 | 400 | 50 | | 8M-864 | 864 | 108 |
| 8M-416 | 416 | 52 | | 8M-872 | 872 | 109 |
| 8M-424 | 424 | 53 | | 8M-880 | 880 | 110 |
| 8M-432 | 432 | 54 | | 8M-888 | 888 | 111 |
| 5M-440 | 440 | 55 | | 8M-896 | 896 | 112 |
| 8M-448 | 448 | 56 | | 8M-904 | 904 | 113 |
| 8M-456 | 456 | 57 | | 8M-912 | 912 | 114 |
| 8M-464 | 464 | 58 | | 8M-920 | 920 | 115 |
| 8M-472 | 472 | 59 | | 8M-928 | 928 | 116 |
| 8M-480 | 480 | 60 | | 8M-936 | 936 | 117 |
| 8M-496 | 496 | 62 | | 8M-944 | 944 | 118 |
| 8M-512 | 512 | 64 | | 8M-952 | 952 | 119 |
| 8M-520 | 520 | 65 | | 8M-960 | 960 | 120 |
| 8M-528 | 528 | 66 | | 8M-968 | 968 | 121 |
| 8M-536 | 536 | 67 | | 5M-976 | 976 | 122 |
| 8M-544 | 544 | 68 | | 8M-984 | 984 | 123 |
| 8M-560 | 560 | 70 | | 8M-992 | 992 | 124 |
| 8M-568 | 568 | 71 | | 8M-1000 | 1000 | 125 |
| 8M-576 | 576 | 72 | | 8M-1008 | 1008 | 126 |
| 8M-584 | 584 | 73 | | 8M-1016 | 1016 | 127 |
| 8M-592 | 592 | 74 | | 8M-1024 | 1024 | 128 |
| 8M-600 | 600 | 75 | | 8M-1032 | 1032 | 129 |
| 8M-608 | 608 | 76 | | 8M-1040 | 1040 | 130 |
| 8M-616 | 616 | 77 | | 8M-1048 | 1048 | 131 |
| 8M-624 | 624 | 78 | | 8M-1056 | 1056 | 132 |
| 8M-632 | 632 | 79 | | 8M-1064 | 1064 | 133 |
| 8M-640 | 640 | 80 | | 8M-1072 | 1072 | 134 |
| 8M-648 | 648 | 81 | | 8M-1080 | 1080 | 135 |
| 8M-656 | 656 | 82 | | 8M-1088 | 1088 | 136 |
| 8M-664 | 664 | 83 | | 8M-1096 | 1096 | 137 |
| 8M-672 | 672 | 84 | | 8M-1104 | 1104 | 138 |
| 8M-680 | 680 | 85 | | 8M-1112 | 1112 | 139 |
| 8M-688 | 688 | 86 | | 8M-1120 | 1120 | 140 |
| 8M-696 | 696 | 87 | | 8M-1128 | 1128 | 141 |
| 8M-704 | 704 | 88 | | 8M-1136 | 1136 | 142 |
| 8M-712 | 712 | 89 | | 8M-1144 | 1144 | 143 |
| 8M-720 | 720 | 90 | | 8M-1152 | 1152 | 144 |
| 8M-728 | 728 | 91 | | 8M-1160 | 1160 | 145 |
| 8M-736 | 736 | 92 | | 8M-1168 | 1168 | 146 |
| 8M-744 | 744 | 93 | | 8M-1176 | 1176 | 147 |
| 8M-752 | 752 | 94 | | 8M-1184 | 1184 | 148 |
| 8M-760 | 760 | 95 | | 8M-1192 | 1192 | 149 |
| 8M-768 | 768 | 96 | | 8M-1200 | 1200 | 150 |
| 8M-776 | 776 | 97 | | 8M-1208 | 1208 | 151 |
| 8M-784 | 784 | 98 | | 8M-1216 | 1216 | 152 |
| 8M-792 | 792 | 99 | | 8M-1224 | 1224 | 153 |
| 8M-800 | 800 | 100 | | 8M-1232 | 1232 | 154 |
公司宗旨：诚信务实 客户至上 质量保证 价格合理
