QS-1412功能特点：
Features:
- 光、机、电、一体化设计，性能更稳定。
Integration of photographic, mechanic and electric technologies, giving more stable performance.
Great processing precision, maximum tolerance at 0.05mm.
- 极高的雕刻速度1000/s。
Extremely high engraving speed, 1000/s.
- 业内领先的连续、快速曲线切割功能：普通机型60/s，先进机型300/s。
The leading technology of uninterrupted and fast curve cutting: with standard model at 60/s and advanced model at 300/s.
- 最短加工路径优化功能，大大提高工作效率。
Optimized function of selecting shortest path, greatly improving working efficiency.
- 用户可选的激光管专用冷水机，大大提高激光管的工作寿命和雕刻效果。
Customer optional cooling water machine for laser tube, greatly prolonging the working life of the tube and bettering engraving effect.
Imported big-diameter galvanized silicon reflection mirror of 10.6um length wave and ZnSe focus lens provide slighter light wane and finer focus.
- 与AutoCAD, CorelDRAW,文泰等各种图形处理软件无缝对接，直接原图输出。
Seamlessly compatible to such image processing softwares as AutoCAD, CorelDRAW, and,Wenti, giving output of original photos.
- 直接支持AutoCAD任意手绘曲线。
Support hand any drawn curves of AutoCAD.
- 支持多种格式的文件，图形格式有BMP、PLT、DXF、GIF、AI等
Support files of various formats such as BMP, PLT, DXF, GIF and AI for image processing.
- 先进的颜色管理，支持任意多种颜色，随意定义雕刻次序，全部或部分一次性输出。
Advanced color management, supporting the combination of any colors, engraving in freely defined sequence, partial or total output in one time.
- 完美的坡度雕刻、灰度图雕刻。
Perfect grade and grayness engraving.
QS-1412技术参数
机型Model |
| QS-1412fashinon model |
激光类型Laser-type | CO2激光管CO2 laser tube | |
激光功率Lader-power |
| 150w |
雕刻面积Engraving area |
| 1350*1200mm |
切割面积]Cutting area |
| 1400*1200mm |
雕刻速度Engraving speed | 0-1000mm/s | |
切割速度Cutting speed | 0-400mm/s | |
重复定位精度Repeating location | ≤±0.01 | |
支持图文格式Graphic format supported | BMP, HPGL(PLT), JPEG, DST, DXF,AI | |
运行系统Moving system | DSP专业控制,微步恒流细分 Professional controlling, micro elegancy | |
通讯接口Communication connection | USB（脱机Off-line） | |
工作电压Working voltage | 220V±10% 50HZ | |
切割平台Cutting platform | 选配多种雕刻工作平台（选配） Equipped with a variety of engraving working tables (Match) | |
辅助装置Auxiliary equipments | 冷却系统,排风系统Cooling system, ventilation system | |
控制软件Controlling software | 齐盛激光专用软件The special software for Qisheng Laser配有中英文界面Has the Chinese and English contact surface | |
外形尺寸Machine dimension |
| 1950*1700*1250 |
自动水冷机Automatic water cooling machine
|
| 用来冷却激光管
|
除尘风机Removes dust the air blower
|
| Cooling system, ventilation system |
亚克力 | 雕刻深度 切割厚度 | 0-5MM 0-30MM |
密度板、木板 | 雕刻深度 切割厚度 | 0-3MM 0-15MM |
玻璃 | 雕刻深度： 不可切割 | 0-1MM |
瓷砖 | 雕刻深度： 不可切割 | 0-1MM |
其他材料 | 视材质而定 |
|
