型号
Model

板框内尺寸
Inner Chase Size

工作速度
Speed

线切长度
Max. Rule Length

电机功率
Motor Power

机器重量
Machine Weight

外形尺寸
Overall
Dimensions

ML2500

2500 x1500mm

11±2
Strokes/Min

<80m

22kw

20000kg

3680x2500x2580mm

ML2200

2200 x1400mm

11±2
Strokes/Min

<80m

18kw

18000kg

3680x2450x2580mm

ML2000

2000x1400mm

13±2
Strokes/Min

<65m

15kw

16000kg

2200x3050x2450mm

ML1800

1800X1250mm

13±2
Strokes/Min

<60m

11.5kw

14000kg

2200x2850x2350mm

ML1600

1600X1250mm

13±2
Strokes/Min

<50m

11kw

12000kg

2220x2650x1950mm

ML1500

1500X1040mm

14±2
Strokes/Min

<48m

7.5kw

8000kg

2050x2500x1950mm

ML1400

1400x1000mm

15±2
Strokes/Min

<45m

5.5kw

6500kg

2050x2400x1900mm

ML1300

1300X920mm

16±2
Strokes/Min

<40m

5.5kw

5600kg

2050x2300x1800mm

ML1200

1200x820mm

20±2
Strokes/Min

<35m

4kw-6H

5000kg

2050x1950x1750mm

ML1100

1040X800mm

20±2
Strokes/Min

<32m

4kw-6H

4500kg

2050x1820x1750mm

PYQ203

930X670mm

23±3
Strokes/Min

<25m

4kw

3000kg

1800x1550x1600mm

ML750

750X520mm

25±3
Strokes/Min

<, 15m

2.2kw-6H

2000kg

1350x1500x1400mm
