Conductivity Analyzer AX410
The Conductivity Analyzer AX410 is designed for use with ABB’s 2 electrode conductivity cells. The transmitter measures conductivity or resistivity with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a perse range of process monitoring and control applications. Applications include demineralisation and reverse osmosis plants, semiconductor industry, power plants, biomedical and pharmaceutical industries and large steam-raising plants in Pulp & Paper, Steel and Chemicals.
- Wall, pipe and panel mount versions with IP 66 / NEMA 4X ingress protection
- Accurate measurements up to 10,000 µS/cm, 18.2MΩ·cm and 8,000 ppm total dissolved solids
- True high purity temperature compensations for all pure water applications
- 2 to 4 current outputs and 3 to 5 relay contacts
- Integral P, PI, PID Control: pulse frequency, pulse length and analog
- Versatile power supply options 85 ... 265 V AC or 12 ... 30 V DC
- High visibility, multi-language display
Conductivity Analyzer AX411
The Conductivity Analyzer AX411 is designed for use with two ABB 2 electrode conductivity cells. The cost-saving transmitter measures conductivity or resistivity with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a perse range of process monitoring and control applications. Applications include demineralisation and reverse osmosis plants, semiconductor industry, power plants, biomedical and pharmaceutical industries and large steam-raising plants in Pulp & Paper, Steel and Chemicals.
- Wall, pipe and panel mount versions with IP 66 / NEMA 4X ingress protection
- Accurate measurements up to 10,000 µS/cm, 18.2 MΩ·cm and 8,000 ppm total dissolved solids
- Two cells, one instrument - reduces cost of investment
- Conductivity difference, ratio, % passage, % rejection and inferred pH calculations
- True high purity temperature compensations for all pure water applications
- 2 to 4 current outputs and 3 to 5 relay contacts
- Versatile power supply options 85 ... 265 V AC or 12 ... 30 V DC
- High visibility, multi-language display
Conductivity Analyzer AX413
The AX413 is designed for use with ABB’s 2 and 4-electrode conductivity cells. The cost-saving analyzer measures low-range µS/cm and high-range mS/cm conductivity simultaneously, with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a perse range of process monitoring and control applications – click on the 'Data' tab to view.
- Two sensors, one instrument - reduces cost of investment
- Accurate measurements down to 0.055 µS/cm and up to
2,000 mS/cm - Concentration measurement up to 15 % NaOH, 18 % HCl,
20 % H2SO4or NaCl, or 40 % H3PO4 - True high purity temperature compensations for all pure water applications
- Problem-free measurements using auto-compensation of sensor fouling
- Dosing control functionality – long dose alarm and initial charge function
Conductivity & pH Analyzer AX416
The Conductivity & pH Analyzer AX416 is designed for use with ABB’s pH and 2-electrode conductivity cells. The cost-saving transmitter simultaneously measures pH and conductivity or resistivity with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a perse range of process monitoring and control applications – click on the 'Data' tab to view.
- Wall, pipe and panel mount versions with IP 66 / NEMA 4X ingress protection
- Accurate measurements up to 14 pH, 10,000 µS/cm, 18.2 MΩ·cm and 8,000 ppm total dissolved solids
- Two sensors, one instrument - reduces cost of investment
- True high purity temperature compensations for all pure water applications
- 2 to 4 current outputs and 3 to 5 relay contacts
- Versatile power supply options 85 ... 265 V AC or 12 ... 30 V DC
- High visibility, multi-language display
