主要技术参数Main technical specification
产品名称Products Name 蓝宝石薄壁管Sapphire tube
材料Materials 光学级蓝宝石optical sapphire(Al2O3)
直径范围Diameter Range (mm) 2.00~300.00
直径公差 Diameter Tolerance (mm) ±0.02
内径范围Inner Diameter Range(mm) 0.20~100.00
内径公差Inner Diameter Tolerance (mm) ±0.02
长度范围Length Range(mm) 2.00~100.00
长度公差Length Tolerance (mm) ±0.02
内孔光洁度Inner hole finish 80/50，60/40,40/20
通光孔径Clear Aperture 80%~99%
表面粗糙度Surface Roughness 0.1μm per Inch
表面质量Surface Quality 80/50，60/40，40/20，20/10
平行度Parallelism (arcminutes) ≤3.5
轴向Orientation of Axis 根据客户要求According to customer requirements
生产能力Production capacity 50~100 pcs / Month
重庆蜀洲科技有限公司是专门从事蓝/红宝石材料（Al2O3）制品的设计、生产企业。公司本着“发展靠市场，市场靠质量，质量靠技术”的理念，一直致力于蓝/红宝石光学制品的研究、开发；设备先进，技术力量雄厚；有能力为各类客户提供世界一流的蓝/红宝石光学产品；也可专门为不同需求的用户设计、研制具有特种需求、标准化及个性化的其它各类晶体元件、蓝宝石光学制品。
本公司主要生产各类规格蓝宝石光学窗口片、蓝宝石圆片、蓝宝石LED衬底、蓝宝石透镜、蓝宝石棱镜、蓝/红宝石圆球、蓝宝石圆棒、蓝宝石激光棒、蓝宝石特殊元件等；产品主要应用于机械仪器仪表、光学仪器、医疗美容仪器、教学科研仪器、半导体、激光技术，军工及航空航天高科技领域等；产品主要销往东南亚、北美、欧洲、俄罗斯、日本、韩国等发达国家和地区，获得国内外客户一致好评。
本公司拥有完整、科学的质量管理体系，通过ISO9001国际质量体系认证，采用国际标准生产蓝/红宝石光学制品。重庆蜀洲科技有限公司以诚信为本，恪守信用，以客户利益为重！欢迎各界朋友莅临本公司参观、指导和业务洽谈。客户的认可，是我们企业最大的荣誉！本公司相信，与贵单位的合作也将一如本公司与其他兄弟单位的合作一样默契、愉快！选择我们，将使贵单位发展的步伐迈得更加稳健！来吧，本公司期待与您们的携手合作！
Enterprise introduction
Chongqing Shuzhou Technology Co., LTD. specializes in the precision design and manufacture of super-hard materials, such as synthetic sapphire & ruby (A12O3). Our company has been committed, based on the concept of “developing by the market, marketing by the quality and high quality by technology”, to the research and development of optical products such as sapphire & ruby. Our equipments are advanced and the technical force is abundant. We are not only capable of providing all kinds of customers with world-class sapphire & ruby optical products, but also able to design and develop other kinds of special，standardized and personalized crystal components and sapphire optical products required by various of customers.
The company mainly produces all kinds of specified sapphire optical window, sapphire discs, sapphire LED substrates, sapphire lens, sapphire prisms, sapphire & ruby ball, sapphire rods, sapphire laser sticks, and special sapphire components, etc. The product is mainly applied in mechanical instrumentation, optical instrument, medical hairdressing apparatus, teaching and scientific research instrument, semiconductor, laser technology, military and aerospace high-tech areas, etc; products are mainly exported to Southeast Asia, North America, Europe, Russia， Japan ，Korea and other developed countries and regions. We have won a high reputation from the customers both home and abroad.
The company has complete and scientific quality management system. Identified by the ISO9001 international quality system, the company manufactures sapphire & ruby optical products according to international standard. Chongqing Shuzhou Technology Co., LTD. adheres to promises, takes honest as fundamental and gives priority to the customers’ benefits! We warmly welcome all friends worldwide to come to our company for visiting, guiding and business negotiations. Your approval of our products is our biggest honor! We firmly believed that our cooperation with you will be harmonious and happy, just like our cooperation with other brother companies. Choosing us, you will make steadily progress in your development! Come on, we are sincerely looking forward to cooperating with you!
联 系 人：赖振宇 先生 （销售 总经理）
电 话：86 023 60303008
移动电话：13527367686
传 真：86 023 60300901
地 址：中国 重庆市北碚区 北碚区歇马镇东风村吴家坝组
邮 编：400712
公司主页：http://www.cqszt.com http://knig816.cn.1688.com
