深圳市凯明节能设备有限公司 Great Light Technology Co.,LTD |
100W路灯参数 100W led street light parameters |
产品型号 | KW-LA100W | | Type | KW-LA100W |
产品规格 | 480*250*90(㎜) | Specifications | 480*250*90(㎜) |
灯杆夹距 | ￠30-60MM | pole diameter | ￠30-60MM |
光源功率 | 100W | Light Source Power | 100W |
光效 | ≥80-100LM/W | Light Efficiency | ≥80-100LM/W |
色温 | 暖白：3500K～4500K 正白：5500-6300K | Color temperature | warm white 3500K-4500K Pure white 5500-6300K |
输入电压 | DC12V/DC24V/AC90V～265V | Input Voltage | DC12V/DC24V/AC90V～265V |
输入频率 | 50～60HZ | Input Frequency | 50～60HZ |
输出电流 | 320-330mA | Output Current | 320-330mA |
驱动电源功率因数 | >0.90 | Driving Power Factor | >0.90 |
驱动电源转化效率 | >85% | Driving Power Transformation Efficiency | >85% |
灯具出光角度 | 横向160度，纵向60度 | Light Angle：Horizontal | Horizontal: 160degree，Vertical: 60degree |
光衰 | 1000小时内<3% | Luminous Decay | (within 1000hs)＜3% |
使用寿命 | >5万小时 | Life Span | ＞50000hs |
光斑形状 | 椭圆光斑 | Light Spot Shape | Elliptical facula |
工作温度范围 | -40℃～50℃ | Working Temperature Scope | -40℃～50℃ |
贮存温度范围 | -30℃～60℃ | Storage Temperature Scope | -30℃～60℃ |
光通量 | 8000LM | Light Source Lumious Flux | 8000LM |
包装尺寸 | | Packing size | |
净重 | 4KG/PCS | Net weight | 4KG/PCS |
毛重 | 4．5KG | Gross weight | 4．5KG |
保修期 | 贰年 | The warranty time | 2 years |
