量程（kg）

Rated load

H

L

B

2-M

50～800

76

54

20

M12

1000

76

55

28

M16

1500～2000

80

54

26

M16

额定载荷Rated Load

50 kg～   2000 kg

精度Precision

0.1

灵敏度Rated output

2.000±0.002mV/V

非线性Nonlinearity

0.1%F·S

滞后Hysteresis

0.1%F·S

重复性Repeatability

0.05%F·S

蠕变Creep(30Min)

0.1%F·S

推荐工作电压Recommended Excitation Voltage

5V—12V( DC)

最大工作电压Maximum Excitation Voltage

15V(DC)

零点平衡Zero Balance

±1%F·S

输入阻抗input impedance

380±20Ω

输出阻抗Output impedance

350±2Ω

绝缘阻抗Insulation Resistance

≥3000MΩ

安全过载率Sate Overload

150%F·S

极限过载率Ultimate Overload

200%F·S

工作温度范围Operating Temperature Range

(-30+70)℃

温度补偿范围Compensated Temperature Range

(-10+60)℃

输出温度影响Temperature Effect On Load

0.05%F·S/10℃

零点温度影响Temperature Effect On Zero

0.05%F·S/10℃

材质Construction

合金钢Alloy Steel

防护等级Protection Class

IP67

量程（kg）

Rated load

D

D1

d

L

H

50～800

52

12

28

140

106

1000

62

16

34

154

108

1500～2000

62

16

34

158

112
