型号Model

ART-1728-A

ART-1728-E(IEC-529)(CNS
14165)

内箱尺寸Internal
dimensions.W×H×D(mm)

1200×1200×1200

1200×1200×1200

外箱尺寸External
dimensions.W×H×D(mm)

1750×1850×1300

1750×1850×1300

水温Water
Temp

Normal

喷水试验种类

Spray
Type

全放水量

Total water
flow(/min)

R1

1.8

IP×1

With in 1～1.5mm/min(in drip
box)

R2

3.2

IP×2

With in 3～3.5mm/min(in drip
box)

S1

24.5

IP×3

角度angle±600,R:400mm,1.1/min

S2

39.2

IP×4

角度angle±1800,R:400mm,1.8/min

喷水口压力

Pressure of

spraynozzle(kgf/
c㎡)

R1

0.1

1.每孔之平均流速率Flow rate of the
water=0.07/min

2.
IP×3，半径Rudius:400mm,开孔数目16个Number of oper.
Holes=16,水流量total water
flow:1.1/min.

3.
IP×4，半径Rudius:400mm,开孔数目25个Number of oper.
Holes=25,水流量total water
flow:1.1/min.

※摆动管半径Radius:200mm,R400mm二种.(For IP×3 IP×4 only
).

R2

0.3

S1

1.0

S2

3.0

测试平台转盘(RPM)Test Specimen
Frame

17RPM

1RPM

喷嘴旋转速度Apray Nozzle Rotation
Speed

23RPM

摆动管对垂直线两侧各60°之摆动，一次来回约4秒.

Swing60° from vertical for 4
seconds at one time.

摆动管对垂直线两侧各180°之摆动，一次来回约12秒.

Swing180° from vertical for 12
seconds at one time.

Material

材料

内箱材质Internal
material

SUS#304

外箱材质External
material

附件Other
Components

Chamber
lamp,Wiper,Casters with Adjusters

电力Power
Source

AC 1￠220V 60/50HZ
4KW
