SPEC

UNIT

1

1227.6

MHz

2

1212.6 ~ 1242.6 (fo±15)

MHz

3

Insertion Lossin BW

2.5max.

dB

4

Ripple in BW

0.6max.(0.4 Typ.)

dB

5

Return Loss in BW

15.0 min.

dB

6

Group Delay Variation

5.0 max.(3.5 Typ.)

ns

7

30min. @1165MHz & 1287.6MHz

dB

40min. @DC ~1105MHz

40min. @1570 ~2000MHz

8

Input Power

3 max.

dBm

9

In/Out Impedance

50

ohm

10

OperationTemperature Range

-40 to +85

℃
