| 单头转盘式高周波 Dial high frequency machine with single head | ||
| 产品特点 function | ||
| ◆高Q值电子振荡管，输出稳定可靠； | ||
| ◆高灵敏火花抑制电路，防止损坏模具； | ||
| ◆转盘式结构，二工位装模，有效提高生产效率； | ||
| ◆气缸顶出定位装置，转盘定位准确度； | ||
| ◆优质进口元器件组装； | ||
| ◆单头转盘加工，一个操作，节省人工。 | ||
| ◆Using a high Q value vibration tube in the machine, so it is stable and reliable in output. | ||
| ◆High sensitive spark depressing circuit is used for preventing mould damage. | ||
| ◆The dial style and three work position to fix the mould, it can improve the production effectively. | ||
| ◆The cyinder propping positioning gadget can make precise positioning of turn plate. | ||
| ◆It is made of a whole set high -quality imported components. | ||
| ◆Processing of single-head rotating disc is feasible to one operator to save manpower. | ||
| 技术规格 Specification | ||
| Model 机 型 | XH-8000A | |
| Power 高周波功率 | 5000W | |
| Power supply 电源电压 | 380V | |
| Electronic power 输入功率 | 8KVA | |
| Rectifier 整流器 | SILICON DIODE 矽二极体 | |
| Vibrationaltube 振荡管 | 7T85RB | |
| Maxpressuere 最大压力 | 500KG | |
| Max gap of electrodes最大电极间隔 | 250mm | |
| Size of acctive horm 焊头活动尺寸 | 200mm | |
| Size ofworking plat 定盘尺寸 | 400x600mm | |
| Time change 时间控制 | 0-10S可调Adjustable | |
| Type of operation 操作方式方 | 全气动控制the whole pneumatic controlling | |
| Size of shape 外形尺寸 | 1000x660x1730 | |
| Net welght 净重 | 400KG |
