我司生产国标、日标、德标汽车线，欢迎来电咨询，来厂考察！
联系电话 13665254891
标准如下
| 规格 | 根数 | 丝径 | 外径 | 导体耗材 | 绝缘厚度 | 绝缘外径 | 绝缘耗材 | 成品重量 |
| 0.20 | 12 | 0.15 | 0.69 | 1.81 | 0.30 | 1.29 | 1.49 | 3.30 |
| 0.25 | 14 | 0.15 | 0.74 | 2.26 | 0.30 | 1.30 | 1.56 | 3.82 |
| 0.30 | 16 | 0.15 | 0.79 | 2.71 | 0.30 | 1.39 | 1.66 | 4.37 |
| 0.40 | 23 | 0.15 | 0.95 | 3.61 | 0.30 | 1.55 | 1.90 | 5.52 |
| 0.50 | 16 | 0.20 | 1.06 | 4.52 | 0.60 | 2.26 | 5.03 | 9.55 |
| 0.75 | 24 | 0.20 | 1.30 | 6.78 | 0.60 | 2.50 | 5.76 | 12.54 |
| 1.00 | 32 | 0.20 | 1.50 | 9.03 | 0.60 | 2.70 | 6.38 | 15.41 |
| 1.50 | 30 | 0.25 | 1.82 | 13.55 | 0.60 | 3.02 | 7.34 | 20.89 |
| 2.50 | 49 | 0.25 | 2.33 | 22.58 | 0.70 | 3.73 | 10.72 | 33.30 |
| 4.00 | 56 | 0.30 | 2.99 | 36.13 | 0.80 | 4.59 | 15.32 | 51.45 |
| 6.00 | 84 | 0.30 | 3.66 | 54.20 | 0.80 | 5.26 | 18.04 | 72.24 |
| 8.00 | 113 | 0.30 | 4.25 | 72.27 | 0.80 | 5.85 | 20.42 | 92.69 |
| 10.0 | 84 | 0.40 | 4.88 | 90.34 | 1.00 | 6.88 | 29.74 | 120.07 |
| 16.0 | 126 | 0.40 | 5.98 | 144.54 | 1.00 | 7.98 | 35.30 | 179.83 |
| 14.0 | 111 | 0.40 | 5.61 | 126.47 | 1.00 | 7.61 | 33.44 | 159.91 |
| 25.0 | 196 | 0.40 | 7.46 | 225.84 | 1.30 | 10.06 | 57.60 | 283.43 |
| 35.0 | 276 | 0.40 | 8.86 | 316.17 | 1.30 | 11.46 | 66.76 | 382.94 |
| 50.0 | 396 | 0.40 | 10.61 | 451.68 | 1.50 | 13.61 | 91.85 | 543.53 |
| 70.0 | 360 | 0.50 | 12.65 | 632.35 | 1.50 | 15.65 | 107.29 | 739.63 |
| 95 | 475 | 0.50 | 14.53 | 858.18 | 1.60 | 17.73 | 130.47 | 988.65 |
| 120 | 608 | 0.50 | 16.44 | 1084.02 | 1.60 | 19.64 | 145.91 | 1229.93 |
