| 多圈精密电位器 534 |
| | | 封装直径 Package Diameter(mm) | 22 | 形状 Shape | 圆形 Round | 转数 Number of Turns | 10 | | 密封型 Sealable | IP40 | 轴 Shaft | 金属 Nickel Plated Rail | 电阻材料 Element | 线绕 Wirewound | | 接线端 Terminal | 接线片焊接/侧 Solder Lug/Side | 输出特性-线性 Taper-Linear | X | 线性度 Linearity | ±0.25% | | 最小阻抗 Resistance-Minimum | 100Ω | 最大阻抗 Resistance-Maximum | 100K | 阻值误差 Tolerance resistance | ±2%~±10% | | 额定功率 Power-Rating(W) | 2 | 旋转角度 Angle of rotation | 3600° | 旋转寿命(无负载)Rotational Life (no load) Cycles | 10000 | | 轴径SHAFT DIAMETER | 6mm | | | | | 产品说明: |
