由于产品规格不同（材质、尺寸等），价格也不同；所以具体价格请以协商后的报价为准。
Pressure Range 压力 | | 200 PSIG |
Sizes 尺寸 | | EC-FFS: 3/4" through 3" 3/4" - 3" |
Axial Travel 轴向位移 | | 1.75" compression; 0.25" elongation 1.75" 压缩; 0.25" 拉伸 |
Bellow Material 波纹管材质 | | 304, 321, or 316 stainless steel, Inconel, Monel, or other alloys 304，321或316不锈钢，镍基合金，蒙乃尔合金或其他合金 |
Ends 接头 | | EC-FFS: Female copper sweat EC-MMT: Painted carbon steel MNPT 扩口铜接头；碳钢螺纹接头 |
Shroud 罩子 | | EC-FFS: Painted 304 Stainless Steel 304不锈钢 |
1：
Bellows & Shroud: 304 Series Stainless Steel, 2-Ply Bellows; 304 S/S Shroud
Ends: Female Copper Sweat
304不锈钢波纹管和罩子，扩口铜接头
2：
Bellows & Shroud: 304 Series Stainless Steel Bellows; C/S Shroud
Ends: Carbon Steel Male NPT
304不锈钢波纹管，碳钢罩子，碳钢螺纹接头
