SERIES&DASH NO. |
H* in./µm ±.0001/2.5 |
ICin./µm(ref) |
B** in./µm ±.0002/5 |
OR in./µm ±.0003/8 | T (30° CONE) in./µm ±.0003/8 | T (20° CONE) in./µm ±.0003/8 |
SUGGESTEDWIREDIAMETERin./µm |
1572-10 | .0010/25 | .0007/18 | .0024/61 | .0008/20 | .0055/140 | .0056/142 |
.0005/13to .0008/20 |
1572-10S | .0010/25 | .0004/10 | .0018/46 | .0008/20 | .0055/140 | .0056/142 | |
1572-12 | .0012/30 | .0006/15 | .0024/61 | .0008/20 | .0055/140 | .0056/142 | .0007/18to .0009/23 |
1572-13 | .0013/33 | .0006/15 | .0025/64 | .0008/20 | .0055/140 | .0056/142 |
.0008/20to .0010/25 |
1572-13S | .0013/33 | .0004/10 | .0021/53 | .0008/20 | .0055/140 | .0056/142 | |
1572-15 | .0015/38 | .0007/18 | .0029/74 | .0010/25 | .0065/165 | .0067/170 |
.0009/23to .0011/28 |
1572-15S | .0015/38 | .0006/15 | .0027/69 | .0008/20 | .0055/140 | .0056/142 | |
1572-17 | .0017/43 | .0006/15 | .0029/74 | .0010/25 | .0090/229 | .0092/234 |
.0010/25to .0013/33 |
1572-17S | .0017/43 | .0006/15 | .0029/74 | .0010/25 | .0065/165 | .0067/170 | |
1572-18 | .0018/46 | .0006/15 | .0030/76 | .0010/25 | .0090/229 | .0092/234 | |
1572-20 | .0020/51 | .0010/25 | .0040/102 | .0015/38 | .0090/229 | .0093/236 |
.0013/33to .0015/38 |
1572-22 | .0022/56 | .0009/23 | .0040/102 | .0015/38 | .0090/229 | .0093/236 | |
1572-25 | .0025/64 | .0013/33 | .0051/130 | .0020/51 | .0115/292 | .0118/300 | .0015/38to .0020/51 |
1572-30 | .0030/76 | .0013/33 | .0056/142 | .0025/64 | .0130/330 | .0134/340 | .0020/51 |
1572-35 | .0035/89 | .0010/25 | .0055/140 | .0030/76 | .0140/356 | .0145/368 | .0020/51to .0025/64 |
1572-40 | .0040/102 | .0010/25 | .0060/152 | .0030/76 | .0140/356 | .0145/368 | .0030/76 |
1572-50 | .0050/127 | .0013/33 | .0076/193 | .0030/76 | .0160/406 | .0165/419 | .0040/102 |
1572-70 | .0070/178 | .0015/38 | .0100/254 | .0050/127 | .0280/711 | .0288/732 | .0050/127 |
1572-100 | .0100/254 | .0020/51 | .0140/356 | .0070/178 | .0380/965 | .0391/993 | .0060/152 |
