Part Number	Feature	PDF	Size (S) (mm)	Thickness (L) (mm)	Rating Voltage (V)	Current (A)	Speed (min?¹)	Air Flow (m³/min)	Static Pressure (Pa)	Noise (dB)	Frequency (Hz)
3610PS-20T-B20	-		92	25	200	0.050	2500	0.800	39.2	35.0	60
3610PS-20T-B30	-		92	25	200	0.100	2600	0.800	43.1	33.5	50
3610PS-20T-B30	-		92	25	200	0.080	3100	0.980	60.7	38.0	60
3610PS-22T-B10	-		92	25	220	0.050	1450	0.460	13.7	23.0	50
3610PS-22T-B10	-		92	25	220	0.040	1800	0.600	19.6	26.0	60
3610PS-22T-B20	-		92	25	220	0.050	2100	0.600	29.4	30.0	50
3610PS-22T-B20	-		92	25	220	0.050	2500	0.800	38.2	35.0	60
3610PS-22T-B30	-		92	25	220	0.100	2600	0.800	43.1	34.0	50
3610PS-22T-B30	-		92	25	220	0.080	3100	0.980	60.7	39.0	60
3610PS-23T-B10	-		92	25	230	0.050	1450	0.460	13.7	22.0	50
3610PS-23T-B10	-		92	25	230	0.040	1800	0.580	19.6	26.0	60
3610PS-23T-B20	-		92	25	230	0.050	2100	0.600	29.4	30.0	50
3610PS-23T-B20	-		92	25	230	0.050	2500	0.800	39.2	35.0	60
3610PS-23T-B30	-		92	25	230	0.090	2600	0.800	43.1	34.0	50
3610PS-23T-B30	-		92	25	230	0.070	3100	0.980	60.7	39.0	60
