LB450-3装箱线

产品优点： 该装箱线由全自动包装机、开箱机、自动装箱机、自动封箱机、自动捆扎机等组成。散状物料经过全自动包装机进行包装，包好的袋装成品通过输送生产线进行理包整理，转向排序，加速缓冲，再以一定的数量自动有序的装入纸箱，通过压平机进行整理，全自动封箱机构按要求封好纸箱，自动捆扎机进行捆扎带，最后由物流线输出。
流程：自动包装→重量选别或金探→汇流整形线→自动开箱机→自动装箱机→振动压平→全自动封箱机→自动捆扎机→暂存段

技术参数：
1.小袋产能：120-150pcs/min
2.小袋重量：≥250g
3.装箱理包动力采用松下伺服马达
4.气动组件采用SMC、Festo等优质产品
5.电气可集散控制，触摸屏显示操作
6.工作气压：≥5kgf/C㎡
7.设备功率：≥5KW（根据配置）

8.整套设备：输送、弯道、Z提等。

LB450-3
Advantages: The packing line is composed of automatic packaging machines, out of the box machine, automatic packing machine, automatic sealing machine, automatic baling presses and so on. Bulk materials through the automatic packaging machine for packaging, including bags of finished good production line management through the packet transmission order, turn order, speed up the buffer, and then to a certain number of cartons loaded automatically ordered by flattening machine finishing, automatic sealing body ording to the requirements of sealed cardboard boxes, automatic strapping machine for banding, the last line of output from the logistics.
Process: Automatic weight sorting or packing→ Exploration → convergence in shaping line payment automatically out of the box machine → → → vibration automatic packing machine automatic sealing machine flatten → → → automatic strapping temporary segment
Technical parameters:
1. Pouch capacity :120-150pcs / min
2. Pouch weight: ≥ 250g
3. Boxing manager package is powered by Panasonic servo motor
4. Pneumatic components by SMC, Festo high-quality products such as
5. Electric can be distributed control, touch screen display operation
6. Working Pressure: ≥ 5kgf / C ㎡
7. Equipment power: ≥ 5KW (depending on configuration)
8. Whole eqwipment: Conveying、Bend、Z Type Elevator.
