主要性能:
802.11b:1,2,5.5,11Mbps;
802.11g;6,9,12,18,24,36,48,54Mbps;
802.11n:(20MHz)MCSO-7,高达 72Mbps , (40MHz)MCSO-7,高达 150Mbps
调制模式：OFDM
峰值速率： 150Mbps
峰值吞吐率：90Mbps
智能电源管理功能
安全模式：802.11 b/g/n,WPA,WPA2,WMM,WMM-PS，WHQL,Cisco CCX
| Hardware |
| Chipset | Ralink RT3070 |
| Host interface | USB type A |
| LEDS | Link/ Activity |
| RF |
| Antenna | Built-On Board |
| Frequency | 2412~2472MHz, ISM band. |
| Transmit Power | 802.11b:19+/-1.5dBm; 802.11g:15+/-1.5dBm; |
| Receive Sensitivity | 802.11b:-84+/-1.5dBm@11Mbps; 802.11g:-69+/-1.5dBm@54Mbps |
| Software |
| Operation System | Windows CE/2000/XP/Vista; Linux 2.6.X;Mac OS X |
| Security | WEP 64/128bit,WPA,WPA2,802.1X ,and802.11i
Cisco CCS V1.0,2.0 and V3.0 Compliant. |
| Operation Conditions |
| Voltage Range* | DC 5.0V±5%,<130mA |
| Operating Temperature | 0℃-40℃ |
| Storage Temperature | -20℃-70℃ |
| Operating Humidity | RH 95%(Non-Condensing) |
| Storage Humidity | RH 95%(Non-Condensing) |
| Physical Specification |
| Dimensions | 68.5*23*10mm |
