立柱底直向侧面十字滑座（三轴）MODEL:LI

Vertical Column & Slide Surface Three-Axis Slide(Cross Type)

Model:LI

Material:FC30 up

uracy:±0.005 m/m

Perpendicular:0.03m/m

Features:

The sliding face is finished in precision grinding

Vertical Column integral compound saddle moves on X,Y&Z axes

Tapered gib

Scraping work for precision assembly (Hydraulic Cylinder or Ball screw optional)

材质:FC30左右

精度:±0.005m/m

直角度:0.03m/m

特点:采用立柱连体十字中座，配合侧面X、Y、Z轴三向传动，滑动面配合整体精密研磨加工，采用斜度梢调整推拔梢、刮花，精度组立完成，（可装置油压缸，或滚珠导螺杆做伺服传动）
