■直接驱动设计
■高速度
■高强度铝型材
■分辨率为10μm, 3μm, 5μm,1μm, 0.5μm, 0.1μm, 50nm, 20nm, 5nm, 2.5nm, 1.22nm.
■零背隙
■不需要维护
| Descriptions | Unit | LMS50DG-C1 | LMS50DG-C2 | LMS50DG-C3 | LMS50DG-C4 |
| Continuous Force1 | N | 63 | 126 | 189 | 252 |
| Peak Force | N | 225 | 450 | 675 | 920 |
| Maximum Velocity4 | m/s | 5 | 5 | 5 | 5 |
| Maximum Acceleration | m/s2 | 100 | 100 | 100 | 100 |
| Maximum Carriage Weight | kg | 2 | 2.5 | 3 | 2.5 |
| Maximum Carriage Lenght | mm | 120 | 180 | 240 | 300 |
Notes:
2. Total module weight = base weight + moving carriage weight.
3. Custom lengths are available.
4. Subject to encoder resolution.
