Scope:
- application:Desktop.laptop.IP camera,IP TV,GPS,game machines
- Chipset:Ralink RT3070,1T1R mode,
- 2.4GHz ISM band,
- USB 2.0 and USB1.1 interface,
- Support Windows OS,Mac OS,Linux OS,
- 802.11b/g/n
- Antenna :I-PEX MHF receptable for external antenna
-
WIFI USB Adapter, 150Mbps wifi network card, Power amplifier wifi adapter.
Main Features:
l 802.11b: 1, 2, 5.5, 11Mbps; 802.11g: 6, 9, 12, 24, 36, 48, 54Mbps
l 802.11n: (20MHz) MCS0-7,Support up to 72Mbps
(40MHz) MCS0-7, Support up to 150Mbps
l OFDM, Peak rate 150Mbps, Peak throughput 90Mbps.
l Power Management
Certification
l Wi-Fi Certification: 802.11 b/g/n, WPA, WPA2, WMM , WMM-PS
l WHQL, Cisco CCX
Hardware |
Chipset | Ralink RT3070, 1T1R mode |
Host interface | USB2.0/1.1, type A ( 4 pin header) |
LEDS | Link/ Activity |
RF |
Antenna | external 5dBi antenna. |
Frequency | 2412~2483.5 MHz, ISM band. |
Transmit Power | 802.11b:18+/-1.5dBm; 802.11g: 15+/-1.5dBm; |
| 802.11n: (HT20), 14+/-1.5dBm, 802.11n: (HT40), 14+/-1.5dBm, |
Receive Sensitivity | 802.11b: -84dBm@11Mbps; 802.11g: -68dBm@54Mbps |
| 802.11n: (HT20), -67dBm@MSC7, 802.11n: (HT40), -63dBm@MSC7, |
Software |
Operation System | Windows CE/2000/XP/Vista/7; Linux 2.6.X; Mac OS X |
Security | WEP 64/128bit , WPA, WPA2, 802.1x, and 802.11i Cisco CCS V1.0, 2.0 and V3.0 Compliant |
Operation Conditions |
Voltage/Current Range* | DC 5.0V ± 5% / <110mA |
Operating Temperature | 0°C - 50°C |
Storage Temperature | -20°C - 70°C |
Operating Humidity | RH 95% (Non-Condensing) |
Storage Humidity | RH 95% (Non-Condensing) |
Application: desktop,laptop,IPTV,IP camera,STB,GPS
Kind: wireless
Style: external
Interface: USB2.0/1.1
Transmission rate: 150Mbps
- Additional Information
| Payment Terms | L/C, T/T, Others |
| Minimum Order | 100pcs |
| Sample Available | Yes |
| FOB Port | Hong Kong,Shenzhen |
| Packing Info | blister or according to the customers' requirement |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe
|
