1250型离子风棒是目前最有效，安全性最高的静电消除方式之一，与9050-4型静
电发生器配合使用，静电消除率高达98%，在效工作距离高达150mm。广泛应用于
包装，印刷，塑料，医药等行业，其特别的保护电路设计可以有效减少打火现象
，并杜绝工作时电击操作人员的危险现象，其采用进口放电针，寿命大大延长，
消除率保持时间更长久。单支离子棒长度可达4000mm，每个静电发生器可连接4支
离子棒，总长度可达16000mm,其采用一次成型的铝合金型材为固定外壳，美观大
方，安装更简易，采用进口高压屏蔽线确保不会对其他电路采用干扰，离子棒全
体密封，防潮防尘，从根本上杜绝短路等危险事故的发生，清洁亦更为方便 ，只
需要用软毛刷或软毛牙刷即可完成清洁工作，省时省力。特别适用于环境恶劣和
高速度高要求的设备之上，如涂布，复合，凹版印刷，分切机，印刷机，流延，
挤出，双拉，横切，包装，制袋，吹膜，淋膜等设备上
9050-4 DS H iss 1 This equipment is entitled to display the CE Mark
Scotts Business Park, Bampton, Devon, GB, EX16 9DN
9050-4
Power Unit
The 9050-4 Power Unit is the heart of
Fraser AC static eliminators. It
supplies the high voltage which
produces the ionisation in most
Fraser Bars, Blowers, Guns etc.
Benefits and Advantages
• The 9050-4 produces high voltage, low current in a controlled and
safe way to
provide the power for Fraser AC static eliminators.
• It has connections for up to four static eliminators.
• Can be used with 50Hz and 60Hz, which is especially useful for
machinery
manufacturers exporting worldwide.
• Contact factory for compatibility with competitors` products.
Construction: Powder coated steel case. Shunt core transformer with
totally
encapsulated windings
Output: 5.5kV.
Current limited to 5mA max
Input: 115V 50/60Hz or 230V 50/60Hz. Please specify.
Switchable 115V to 230V model also available.
Can work with 50Hz or 60Hz unlike many competitive products.
Illuminated mains switch and fuse (230V: 400mA, 115V: 800mA) IEC
connector and 2m mains cable.
Maximum Load: 1250 Bar and derivatives:12m of combined Bar and HT cable
4100 Ionised Airgun: 1 Gun with 10m HT cable or 2 Guns with 5m HT
cable
Safety: The design is current limited to 5mA. If more current is drawn
then the
windings will shut down. Power will restart when the excessive load or
fault is removed.
1250 /1250-S DS iss 1
How It Works:
The 1250 works by applying high voltage to an emitter in a controlled
and safe way. The electric field around the emitters ionises the
air - breaking it up into positive and negative ions. These ions
neutralise
static electricity by being attracted to charges of the opposite
polarity.
Unused ions quickly dissipate into the atmosphere.
1250 / 1250-S
Static Eliminators
Powerful performance and
market-leading reliability make the
1250 and 1250-S the first choice
static eliminators for major
manufacturers
The 1250 and 1250-S neutralise static electricity on sheet, web and
similar processes throughout the plastics, packaging, converting and
related industries. They are equally suitable for food, medical,
pharmaceutical and many cleanroom applications.
Benefits and Advantages
Peformance
• The modern design gives high performance and completely shockless
operation.
• Stay-sharp etched emitters for better long term performance.
• Emitters at 10mm pitch provide the most intense field of static
neutralisation.
• Advanced Hi-Flex polyurethane covered cable, rated at 30kV, suitable
for
processes from robots to high speed machinery.
Reliability
• All electronic components are fully encapsulated for maximum
reliability.
• Robust construction ensures a long life of high performance.
Ease of Use
• Simple to install - with fixed mounting studs (1250) or studs sliding
in slot (1250-S).
• Operating distances of up to 150mm, best distance 20 - 50mm.
• Washable and easy to clean.
• Wide range of options to extend usability. See next page.
Technical Specification
1250-S
The 1250-S has M4 x 20mm hexagon
head mounting studs which slide in a groove
on the underside of the bar.
This gives fast and simple installation.
1250
The 1250 has fixed M4 x 20mm studs
positioned 20mm from each end, and in the
middle for longer bars.
Length: From 60 mm to 6 m.
Construction: Anodised aluminium, epoxy resin, PVC and hardened etched
emitters.
Cable: Hi-Flex polyurethane covered, 30kV screened cable with 25mm
bend radius. Standard length is 2m - longer lengths up to a
maximum of 10m can be specified at time of order (subject to
maximum load on power unit)
90° cable exit option. Bars may be supplied in series - joined by
cable
Power Unit Use with Fraser 5.5kV Power Units - see Datasheets.
Safety: 5mA maximum current from Power Unit. High voltage resistance
inside bars further limits current below 50μA.
Mounting: See sketches below to show 1250 and 1250-S options.200mm x
20mm steel fixing strips are supplied with each bar.
Temperature: 60°C
Standards: CE.
UL (US and C) Listing is a free of charge option.
Variants
EX - ATEX For hazardous areas see EX-1250 Datasheet.
Airboost For extending the range up to 500mm, see 1250-AB Datasheet.
Balanced: For high tech applications where an accurate electrical ion
balance
is required, see 1250-50 Datasheet.
High Charge: See Super 80 Datasheet - considered by many to be the most
powerful static eliminator bar of its type available.
Combination: A passive static discharger may be combined with a 1250,
for
speeds over 1000m/min.
