EMC300A电磁相容.传导干扰测试系统   EMC300A test system

包括1台EMC300A,1台EMC200A,2*500W隔离变压器,1台1000W隔离变压器，电脑一台（自备）。

Including 1 unit of EMC300A, 1 unit of EMC200A,with two 500W isolation transformer, 1 unit of isolation transformer and a computer (self supply).

电子、电器产品的电磁兼容（EMC）问题日益受到重视，尤其是欧美等发达国家，更是强制执行。以前，由于没有合适的专业检测仪器，不少出口企业为此深感棘手，不但付出了大量的人力、物力，而且影响了产品的开发进程。现在，再不必为此烦恼！电磁兼容·传导干扰测试系统的成功研制，将使您的工作变得轻轻松松。

More and more attention has been drawn to the Electromagnetic compatibility of electrical and electronic products, especially in the developed countries in Europe and America, it is enforced. It was quite hard for many exportation enterprises before due to lack of proper professional testing instrument; not only they spent lots of human and material resources, but also the development progress of products was influenced. Now, no more trouble in it! The successful development of EMC300A Electromagnetic compatibility & conducted Interference Testing system will make your job easy.

功能及技术指标：

◆测量峰值、准峰值和平均值,范围：20dBμV-130dBμV(9kHz-150kHz);10dBμV-90dBμV(150kHz-30MHz)

◆频率扫描范围：9kHz～150kHz:200Hz，150kHz-30MHz:9kHz

◆频率扫描步长：100Hz/200Hz/400Hz/(9kHz-150kHz),5kHz/10kHz/20kHz(150kHz-30MHz)

◆扫描间隔：50ms/100ms/200ms(9kHz-150kHz),5ms,10ms,20ms(150kHz-30MHz)

◆接收机基本准确度：±3 dBuV

◆输入阻抗50Ω,最大输入信号2V,并在5V处保护

◆采用CISPR标准规定的50Ω/50μH+5Ω单相模拟电源网络

◆满足FCC,EN55015,EN55022,GB17743等标准的测试要求,为了方便用户,标准自由设定

◆本系统提供中英文应用软件,工作时必须与PC(电脑)机通讯,所有数据和曲线由PC机直接显， Windows98/2000/XP下运行

Specifications：

⑴Measure the PK, QP and Av, with the rang: 9kHz~150kHz:20dBµV~130dBµV;

150kHZ~30MHZ:10dBµV~90dBµV;

   ⑵ Frequency scanning range: 9kHZ~150kHZ (Band width: 200HZ);

150kHZ-30MHZ (Band width: 9kHz);

   ⑶ Frequency scanning step length: 9kHZ-150kHZ: 100HZ/200HZ/400HZ;

 150kHZ-30MHZ: 5kHZ/10kHZ/20kHZ;

   ⑷ Scanning interval: 50ms/100ms/200ms (9kHZ-150kHZ),

5ms/10ms/20ms(150kHZ-30MHZ).

   ⑸ basic accuracy of receiver:±3dBuV;

   ⑹ Input resistance 50Ω, Max. input signal 2V, and it is protected at 5V;

   ⑺ it uses 50Ω/50µH+5Ω single phase V-type simulative power supply network according to CISPR standard;

   ⑻ meet the test requirements of the standards such as FCC, EN55022, GB17743 etc, and the standard can be set freely, for the convenience of customer;

   ⑼ this system provides Chinese and English application software, it must communicate with a PC (computer) when operating, all the data and curves will be displayed directly by the computer, it operates under Windows98/2000/XP,.
