CP SNT 120W 24V 5A View with Tabs|List View

| General ordering data | | Order No. | 8708670000 | | Type | CP SNT 120W 24V 5A | | Version | Power supply, switch-mode power supply unit | | EAN | 4032248380831 | | Qty. | 1 pc(s). | | |
| Dimensions | | Length | 110 mm | | Width | 65.5 mm | | Height | 125 mm | | Weight | 0.65 kg | | |
| Temperatures | | Operating temperature | -10 °C...+70 °C (Derating ab 55 °C) | | Storage temperature | -20 °C...+85 °C | | |
| Input | | Conductor connection system | Screw connection | | Connection range | AWG26-12 (0.1-4.0 mm²) | | Input current | 3 A @ 115 V AC / 2 A @ 230 V AC | | Input frequency | 50/ 60 Hz | | Input fuse | Fusible link 4 A (T) / 250 V | | Input voltage (voltage mode input) | 88...132 V AC/176...264 V AC selectable; 250...370 V DC | | Surge protection | Varistor | | |
| output | | Conductor connection system | Screw connection | | Connection range | AWG26-12 (0.1-4.0 mm²) | | Control at 10...100% load | < 2 % | | Control at input voltage | 0.5 % | | Mains failure bridge-over time | 20 ms @ 115 V AC / 20 ms @ 230 V AC | | Max. capacitance at output | 40000 µF | | Max. residual ripple | < 100 mVPP/ bandwidth 20 MHz | | Output current | 5 A | | Output voltage | 24...28 V DC (adjustable via potentiometer) | | Overload protection | 105 %..130 % Iconstof max. output load; automatic reset | | Parallel connection option | Recommended with diode module | | Status relay / CO contact | 250 V AC (max. 30 V DC) / 1 A | | Surge protection | 29...34 V | | output power | 120 W | | |
| General data | | Degree of efficiency at max. load | 84 % | | Depth | 100 mm | | EMC standards | EN 55011, EN 55022, EN 55024, EN 61000-6-2, 3 | | Installation advice | Clearance: above/below ≥ 3 cm | | Low Voltage Directive | 73/ 23/ EWG | | Mounting position, installation notice | horizontally, on terminal rail TS 35 | | Operating temperature | -10 °C...+70 °C (Derating ab 55 °C) | | Power factor correction | No | | Standards | EN 60950 (SELV) | | Status indication | Green LED | | |
| Insulation coordination | | Protection class | IP 20 | | electrical isolation, input-earth | 1.5 kV | | electrical isolation, input-output | 3 kV | | electrical isolation, output-earth | 0.5 kV | | |
| Notes | | Note, technical data | For redundancy operation or to maintain the alert function, only operate with diode module. The internal varistor found in a switch-mode power supply does not replace the need for surge protection within a system. | | |
| Classifications | | ETIM 2.0 | EC001039 | | ETIM 3.0 | EC001039 | | ETIM 4.0 | EC002541 | | UNSPSC | 30-21-18-01 | | eClass 4.1 | 27-24-04-10 | | eClass 5.1 | 27-04-90-02 | | eClass 6.0 | EC27049201 | | |
| Downloads | | PDF | Warranty information | | |
