这种自动泵适合于从400lb (180kg) 的桶中取出油. 通过移动的螺栓可以将泵固定在桶上，同时不会影响泵的正常吸油和在桶内转动.
泵配置排空阀，可以避免气泡的产生，因此非常适合提供高压润滑剂.
此款泵还可以输送酒精、乳化沥青、汽油、溶剂油、石油、植物油和其它无腐蚀性的液体.
Recommended operating air pressure: 100 psi.
Maximum operating air pressure: 200 psi.
Maximum fluid pressure: 200 psi.
Lubricant outlet: 1” BSP (RP 1 UNI-ISO 7/1.Air inlet: ¼” BSP (RP ¼ UNI-ISO 7/1.
Air exhaust port: Ø 5/8”
Lubricant inlet: 0,30 cm 3
Displacement: Ø 168 cm 3 /cycle
Air consumption: 800 NL/min. at 7 bar.
Stroke: 98,5 mm.
Weight: 9 Kg.
INSTALLATION/OPERATION:
Maintenance.
The pump must be cleaned periodically and whenever
there is a change in the type of fluid to be handled. For
routine maintenance a repair kit Part No. 72211 is
available.
'
