天浩工厂供应百兆8口塑料轻便壳以太网交换机
中文说明
| 产品描述： TH-1008X是一款8 口10/100M MINI型快速以太网交换机，高集成度桌面型设计，小巧、轻便，操作简单，具有安装方便、性能稳定、转发速率高等特点，它是一款专门为了满足家庭、宿舍、小型企业等网络互联而设计的性价比极高的产品。采用存储转发技术，结合动态内存分配，确保有效的分配到每一个端口。流量控制保证节点在传送和接收时，尽可能的避免数据包丢失。兼容10Base-T和100Base-TX两种网络环境，端口速度10/100M自动匹配。LED面板灯动态显示电源、网路通断情况。 产品规格： · 符合IEEE 802.3、IEEE 802.3u标准 · 流控方式：全双工采用IEEE 802.3x标准，半双工采用Backpressure标准 · 存储-转发体系结构 · 8个10/100M自适应RJ45端口，支持端口自动翻转（Auto MDI/MDIX） · UTP端口支持自动协商功能，自动调整传输方式和传输速率 · 支持MAC地址自学习 · 动态LED指示灯，提供简单的工作状态提示及故障排除 · 外置电源，桌面迷你型塑料/钢壳结构设计 |
产品规格：
|
支持的标准和协议 |
IEEE 802.3、IEEE 802.3u、IEEE 802.3x | |
|
端口 |
8个10/100M自适应RJ45端口（Auto MDI/MDIX） | |
|
网络介质 |
10Base-T：3类或3类以上UTP | |
|
过滤和转发速率 |
10Mbps：14880pps | |
|
LED指示 |
每个端口 |
Link/Act（连接/工作），100Mbps（速度） |
|
其它 |
Power（电源） | |
|
使用环境 |
工作温度：0ºC～40ºC；存储温度：-40ºC～70ºC | |
|
电源及功耗 |
外置电源适配器输出：9VAC 功耗：最大3.4W | |
英文说明
Product Description:
TH-1008X is a 8 ports 10/100M MINI Fast Ethernet switches, highly integrated desktop design, compact, lightweight, simple operation, with easy installation, stable performance, high forwarding rate, it is a specialized In order to meet the family, houses, small businesses, such as the Internet network designed to offer great value for money products. Using store-and-forward technology, combined with dynamic memory allocation, to ensure effective distribution to each port. Node in the flow control to ensure that when sending and receiving as much as possible to avoid packet loss. Compatible with 10Base-T and 100Base-TX two types of network environment, port 10/100M auto-match speed. LED panel light dynamic display power-off situation in the network.
Product specifications:
· Comply with IEEE 802.3, IEEE 802.3u standards
· Flow control methods: the use of full-duplex IEEE 802.3x standard, half-duplex adopt Backpressure standards
· Storage - forward architecture
· 8 10/100M adaptive RJ45 ports support auto-flip port (Auto MDI/MDIX)
· UTP port supports auto-negotiation function, automatically adjusts the transmission and transfer rate
· Support MAC address self-learning
· Dynamic LED indicator light to provide a simple working condition and troubleshooting tips
· External power supply, desktop mini plastic/steel structure design
Product specifications:
|
Standards and protocols supported |
IEEE 802.3、IEEE 802.3u、IEEE 802.3x | |
|
Port |
8 10/100M adaptive RJ45 Port (Auto MDI / MDIX) | |
|
Network Media |
10Base-T: 3 or above UTP category 3 | |
|
Filtering and forwarding rate |
10Mbps：14880pps | |
|
LED instructions |
Each |
Link/Act，100Mbps |
|
Other |
Power | |
|
Use of environmental |
Operating temperature: 0 º C ~ 40 º C; Storage temperature: -40 º C ~ 70 º C | |
|
Power supply and consumption |
External power adapter output: 9VAC power consumption: 3.4W maximum | |
