日本东丽LCP Siveras L204T40相关型号及产品介绍,应用介绍:
Product
Generic Symbol
Flame Rating Density
(g/cm³)Flexural Modulus
(MPa)Siveras™ L204G35E J LCP V-0 (0.380 mm) 1.65 (ASTM D792) 14000 (ASTM D790) Siveras™ L304G35 H LCP V-0 (0.200 mm) 1.65 (ASTM D792) 13000 (ASTM D790) Siveras™ L304G35 LCP V-0 (0.200 mm) 1.65 (ASTM D792) 13500 (ASTM D790) Siveras™ L304M35 H LCP V-0 (0.380 mm) 1.67 (ASTM D792) 11500 (ASTM D790) Siveras™ L304M35 LCP V-0 (0.380 mm) 1.68 (ASTM D792) 13000 (ASTM D790) Siveras™ L304M50 LCP V-0 (0.380 mm) 1.82 (ASTM D792) 17000 (ASTM D790) Siveras™ L304X35 LCP V-0 (0.380 mm) 1.67 (ASTM D792) 11500 (ASTM D790) Siveras™ LX70G25 J LCP V-0 (0.380 mm) 1.57 (ASTM D792) 14500 (ASTM D790) Siveras™ LX70G35 C LCP V-0 (0.380 mm) 1.64 (ASTM D792) 13500 (ASTM D790) Siveras™ LX70G35 F LCP V-0 (0.380 mm) 1.66 (ASTM D792) 15000 (ASTM D790) Siveras™ LX70G50 C LCP V-0 (0.380 mm) 1.77 (ASTM D792) 17500 (ASTM D790) Siveras™ LX70M30 H LCP V-0 (0.380 mm) 1.62 (ASTM D792) 12000 (ASTM D790) Siveras™ LX70M35 H LCP V-0 (0.380 mm) 1.68 (ASTM D792) 13000 (ASTM D790) Siveras™ LX70M50 H LCP V-0 (0.380 mm) 1.80 (ASTM D792) 15500 (ASTM D790) Siveras™ LX70T35 LCP V-0 (0.380 mm) 1.68 (ASTM D792) 13000 (ASTM D790)
日本东丽LCP Siveras L204T40：
Electronics & Information Materials
SIVERAS® Liquid Crystal Polyester Resin
SIVERAS® is a super engineering plastic developed using Toray's polymer technology. Boasting superior vibration absorption characteristics with its outstanding strength and high modulus of elasticity, SIVERAS® has excellent dimensional stability and moldability (e.g., thin-wall fluidity). With these characteristics, SIVERAS® finds uses in connectors, sensors and other electronic components and CD pickup parts, and in copying machine and fax components in office and audio-visual equipment.
日本东丽LCP Siveras L204T40：
“Siveras”是以东丽公司的高分子技术为基础开发成功的超级工程塑料。该产品具有强度高、弹性好、吸收震动性、尺寸稳定性、成型性（薄壁流动性）好等优点，使用于生产连接器、传感器等电子零件以及激光唱片机拾音器、复印机、传真机的零部件等办公自动化设备和音像设备。
日本东丽LCP Siveras L204T40：
Siveras L204A35 LCP Toray Resin Company
Siveras L204G35 LCP Toray Resin Company
Siveras L204G35H LCP Toray Resin Company
Siveras L204G35J LCP Toray Resin Company
Siveras L204G35R LCP Toray Resin Company
Siveras L204G50EC LCP Toray Resin Company
Siveras L204M35 LCP Toray Resin Company
Siveras L204M50 LCP Toray Resin Company
Siveras L204T40 LCP Toray Resin Company
Siveras L304A35 LCP Toray Resin Company
Siveras L304G35 LCP Toray Resin Company
日本东丽LCP Siveras L204M50：
Physical property Mechanical property Heat property Electrical property Molding property
| Property | Test Condition | Test Method ISO | Units | GF reinforced | ||
| High flow | ||||||
| L304G35H | ||||||
| >LCP-GF35< | ||||||
| Water Absorption | 24hrs. in 23℃ water | ASTM D570 | % | 0.01 | ||
| Specific Gravity | ASTM D792 | - | 1.65 | |||
| Tensile strength | ASTM D638 | MPa | 135 | |||
| Tensile elongation at Break | ASTM D638 | % | 3 | |||
| Flexural Strength | ASTM D790 | MPa | 160 | |||
| Flexural Modulus | ASTM D790 | GPa | 13 | |||
| Rockwell Hardness | ASTM D785 | R,M Scale | R105 | |||
| Izot impact V-notched | ASTM D256 | J/m | 75 | |||
| Heat Deflection Temp High Load | 1.82MPa | ASTM D648 | ℃ | 270 | ||
| Flammability | UL94 | rank/thickness mmt | V-0(0.20) | |||
| Linear Thermal Expansion | ASTM D696 | ×10-5/K | 0.6〜2.5 | |||
| CTI | UL 746A | UL Index | 3Equivarent | |||
| Dielectric Strength | ASTM D149 | kV/mm | 50 | |||
| Dielectric Constant | ASTM D150 | − | 4.1 | |||
| Mold shrinkage(Machine Direction) | 80×80×1mmt | Toray Method | % | -0.03 | ||
| Mold shrinkage(Transverse Direction) | 80×80×1mmt | Toray Method | % | 0.83 | ||
