AB-GAB系列 二位二通多用途(管式/板式)电磁阀 |
 | 产品特点： AB,GAB系列多用途电磁阀是引进日本CKD公司产品，适用于多种介质(空气、煤气、水各种油类）及真空控制，性能好，寿命长，应用范围广。
AB/GAB Series solenoid valves are introduced from CKD Co. of Japan. They are suited to various media(air, gas, water and oil of all kind), and vacuum control. They feature high performance, long cycle life, widely application. |
图形符号：
型号注释：
技术参数： 项目/型号 | 接管
螺纹 | 公称通径
mm | CV值 | 有效截面积
mm2 | 最高工作压差(MPa) | 空气 | 水、煤油 | 油(50cst) | 蒸气 | AC | DC | AC | DC | AC | DC | DC | AB310-1-1 | ZG1/8 | 1.5 | 0.1 | 1.8 | 2.50 | 2.50 | 2.50 | 2.50 | 2.50 | 2.50 | 0.10 | AB310-1-2 | 2.0 | 0.15 | 2.7 | 1.50 | 1.50 | 1.50 | 1.50 | 1.50 | 1.50 | 1.00 | AB310-1-3 | 3.0 | 0.31 | 6.2 | 1.06 | 0.50 | 0.70 | 0.50 | 0.50 | 0.50 | 0.70 | AB310-1-4 | 3.5 | 0.42 | 8.2 | 0.60 | 0.40 | 0.50 | 0.40 | 0.40 | 0.40 | 0.50 | AB310-1-5 | 4.0 | 0.54 | 10.5 | 0.40 | 0.25 | 0.30 | 0.25 | 0.25 | 0.25 | 0.30 | AB310-1-6 | 5.0 | 0.80 | 15.3 | 0.20 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | AB310-2-1 | ZG1/4 | 1.5 | 0.1 | 1.8 | 2.50 | 2.50 | 2.50 | 2.50 | 2.50 | 2.50 | 0.10 | AB310-2-2 | 2.0 | 0.15 | 2.7 | 1.50 | 1.50 | 1.50 | 1.50 | 1.50 | 1.50 | 1.00 | AB310-2-3 | 3.0 | 0.31 | 6.2 | 1.06 | 0.50 | 0.70 | 0.50 | 0.50 | 0.50 | 0.70 | AB310-2-4 | 3.5 | 0.42 | 8.2 | 0.60 | 0.40 | 0.50 | 0.40 | 0.40 | 0.40 | 0.50 | AB310-2-5 | 4.0 | 0.54 | 10.5 | 0.40 | 0.25 | 0.30 | 0.25 | 0.25 | 0.25 | 0.30 | AB310-2-6 | 5.0 | 0.80 | 15.3 | 0.20 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | 0.15 | AB410-2-1 | ZG1/4 | 1.5 | 0.1 | 1.8 | 5.00 | 4.00 | 4.50 | 4.00 | 4.00 | 4.00 | 1.00 | AB410-2-2 | 2.0 | 0.15 | 2.7 | 3.00 | 2.50 | 2.7 | 2.50 | 2.50 | 2.50 | 1.00 | AB410-2-3 | 3.0 | 0.31 | 6.2 | 1.50 | 0.90 | 1.30 | 0.90 | 0.90 | 0.90 | 1.30 | AB410-2-4 | 3.5 | 0.42 | 8.2 | 1.20 | 0.60 | 0.90 | 0.60 | 0.60 | 0.60 | 0.90 | AB410-2-5 | 4.0 | 0.54 | 10.5 | 1.00 | 0.50 | 0.70 | 0.50 | 0.50 | 0.50 | 0.70 | AB410-2-6 | 5.0 | 0.80 | 15.3 | 0.60 | 0.25 | 0.40 | 0.25 | 0.25 | 0.25 | 0.40 | AB410-2-7 | 7.0 | 1.0 | 26.4 | 0.25 | 0.10 | 0.20 | 0.10 | 0.10 | 0.10 | 0.20 | AB410-3-1 | ZG3/8 | 1.5 | 0.1 | 1.8 | 5.00 | 4.00 | 4.50 | 4.00 | 4.00 | 4.00 | 1.00 | AAB410-3-2 | 2.0 | 0.15 | 2.7 | 3.00 | 2.50 | 2.7 | 2.50 | 2.50 | 2.50 | 1.00 | AB410-3-3 | 3.0 | 0.31 | 6.2 | 1.50 | 0.90 | 1.30 | 0.90 | 0.90 | 0.90 | 1.30 | AB410-3-4 | 3.5 | 0.42 | 8.2 | 1.20 | 0.60 | 0.90 | 0.60 | 0.60 | 0.60 | 0.90 | AB410-3-5 | 4.0 | 0.54 | 10.5 | 1.00 | 0.50 | 0.70 | 0.50 | 0.50 | 0.50 | 0.70 | AB410-3-6 | 5.0 | 0.80 | 15.3 | 0.60 | 0.25 | 0.40 | 0.25 | 0.25 | 0.25 | 0.40 | AB410-3-7 | 7.0 | 1.0 | 26.4 | 0.25 | 0.10 | 0.20 | 0.10 | 0.10 | 0.10 | 0.20 | AB410-3-8 | ZG3/8 | 10.0 | 1.88 | 40.6 | 0.10 | 0.05 | 0.10 | 0.05 | 0.05 | 0.05 | - | AB410-4-8 | ZG1/2 | 10.0 | 1.88 | 40.6 | 0.10 | 0.05 | 0.10 | 0.05 | 0.05 | 0.05 | - |
|
项目 | AB310 GAB310 | AB410 GAB410 | 额定电压(V) | AC:110,220,24, DC:12,24,48,100 | 频率(Hz) | 50 | 60 | 50 | 60 | 视在功率(VA) | 起动时 | 20.0 | 16.0 | 35.0 | 27.0 | 保持 | 14.0 | 11.0 | 22.0 | 17.0 | 消耗功率(W) | AC | 6.0 | 4.2 | 8.3 | 6.2 | DC | 11.0 | 11.0 | 11.0 | 11.0 | 许可电压范围 | ±10% |
|
'
