设备特点 Equipment Features

 机械联动，保证了组角的同步性和准确性；

◆ 内角定位上下、前后调定装置，用于加工不同形状和尺寸的型材。

◆ It’s used for connecting 90° angle of aluminum window and door with multiplayer corner connector. Adopts

pneumatic control for operation.

◆ Adopts mechanical linkage structure, realizing completely synchronous corner crimping.

◆ Inner corner locating device adopt adjustable locating device. It is suitable for various sections and sizes.

气源工作压力        Air pressure                               0.5-0.8MPa

耗气量              Air consumption                            120L/min

总组角压力          Corner crimping pressure                   85KN

组角缸运动行程      Corner crimping movement journey           75mm

主定位块调整范围    Adjustable arrange of main location block  50 mm

加工型材高度(最大)  Max profile height                         120 mm

外形尺寸            Dimension                                  1240×756×680mm

重量                Weight                                     300kg
