设备特点 Equipment Features

◆ 采用进口硬质合金锯片;

◆ 压料机构上下、前后可调;

◆ 封闭状态切削，更安全、可靠;

◆ 喷淋冷却装置，实现快速冷却。

◆ Saw blade is made from horniness alloy driven by powerful motor.

◆ Adjustable clamping system in front,back,up and down direction.

◆ Closed protective covering makes the operation safety.

◆  Spyaying cooling system

主要规格及技术参数 Main specification and technical parameter

电源/功率          Power supply / Power                380V 50Hz / 2.2kW

工作气压           Operation air pressure                 0.5〜0.8Mpa

耗 气 量           Air consumption                       /

电机转速           Motor rotary speed                   2840r/min

锯切宽度×高度     Cutting width X height                 /

锯片尺寸           Blade size                          φ450×φ30/φ500×φ30

外型尺寸           Contour dimension                   1500×1300×1300mm

重量               Weight                              600kg
