1L
series share plow is a four-wheel
tractor mounted plow, mainly used for plowing loam, the sand loam , cultivated
and dry land.
Advantages:
1.Body of this farm plow is
steel plate, more strong.
2.This tractor mounted farm
plow has good efficiency
3. The mouldboard plow is in
simple adjustment
4. Wide scope of application
5.The width of plow share
could be 25cm,30cm,35cm.
6. Material of plough tip is
65Mn steel
7.The Working depth of
mounted plow could be adjusted
型号 Model | 单位 | 1L(G)-2-25 | 1L(G)-3-25 | 1L(G)-4-25 | 1L(G)-3-35 | 1L(G)-4-35 | 1L(G)-5-35 |
工作幅宽 Working width | mm | 500 | 750 | 1000 | 1050 | 1400 | 1750 |
工作深度 Working depth | mm | 200-250 | 220-270 |
犁体数量 Number of bottoms | | 2 | 3 | 4 | 3 | 4 | 5 |
整机重量 Total weight | kg | 120 | 230 | 310 | 400 | 510 | 650 |
配套动力 Matched power | hp | 25 | 40 | 60 | 70 | 90 | 120 |
