全悬挂中耙系列  Full Suspension Medium Type Disc Harrow

Disc harrow is mainly applicable to clean the crop residue before tillage, break the hardened a break the hardened soil and  return the chopped straw to the soil, and  also can crash the soil after tillage and level the land.

It can be used as tillage machine instead of plow on the cultivated land. With the efficient productivity, reasonable utilization of the power, great ability of cutting and shattering the soil , the soil surface is smooth and loosening after harrowing, it is well suitable for heavy clay soil, waste land and weedy field as well.

Advantages:

1.It is a mounted medium disc harrow for 30-80hp tractor .

2.Notched disc blade of this tractor offset disc harrow in front, and flat plough disc in rear.

3.Fit the scraper for each disc blade to clean the objects.

4. The working depth can be adjusted freely



型号 Model	单位unit	1BJX-1.6	1BJX-1.8	1BJX-2.0	1BJX-2.2	1BJX-2.4	1BJX-2.5
工作幅宽Working width	mm	1600	1800	2000	2200	2400	2500
工作深度Working depth	mm	140
耙片数量Q’ty of disc		14	16	18	20	22	24
整机重量Total weight	kg	350	380	420	470	540	650
配套动力Matched power	hp	30	40	50	60	70	80
挂接方式Linkage		I类三点悬挂Three point suspension I type	II类三点悬挂Three-point suspension II type

​
