型号Model

L280X700G

床身上最大工件回转直径Max. swing over bed

Φ280mm

最大工件长度Distance between centers

700mm

主轴孔径Spindle bore

26mm

主轴锥孔Taper of Spindle bore

MT4

主轴转速范围Range of Spindle speeds

125-2000rpm

尾架套筒锥度Taper of tailstock quill

MT2

车削公制螺纹螺距Metric threads can be cut

0.2-4mm

车削英制螺纹螺距Inch threads can be cut

8-56TPI

电机功率Motor power

850W

重量（净重/毛重）NW/GW

180/210Kg

包装尺寸Package size（L×W×H）

1390X700X630mm
