2696刻度盘技术参数

Counting Capacity, Maximum Turns 10
For Shaft Diameter 1/4”
For Bushing Diameter 3/8”
Depth: Maximum, from Face of Panel 0.900”
Shaft Extension: Maximum, from Face of Panel 0.781”
Minimum, from Face of Panel 0.620”
Bushing Extension: Maximum, from Face of Panel 0.300”
Locking Mechanism Positive Action
Weight, Nominal 16 Grams
Number of Set Screws 1
Numeral Height 0.050”
Knob Material Black Plastic
Dial Finish White Numerals on Black Matte
Housing Finish Satin Chrome
Operating Temperature Range –55°C to +71°C
